2824 [SP 2:SW Tmng:TE] DFU
Adjusts the bias/voltage switch timing of the paper transfer roller/discharge plate at
the paper trailing edge between the erase margin area and the image area.
Middle: 182 mm/sec, Low: 85 mm/sec
2-824-001 PTr:Mid:1st *ENG [0 to 50 / 0 / 2 mm/step]
2-824-002 PTr:Mid:2nd *ENG
2-824-003 PTr: Low : 1st *ENG
2-824-004 PTr: Low : 2nd *ENG
2-824-005 SepaDC:Mid:1st *ENG
2-824-006 SepaDC:Mid:2nd *ENG
2-824-007 SepaDC:Low:1st *ENG
2-824-008 SepaDC:Low:2nd *ENG
2830 [SP 2: EnvCor] DFU
Middle: 182 mm/sec, Low: 85 mm/sec
2-830-013 SepaDC:Mid:1st *ENG [1 to 100 / 30 / 1 /step]
Adjusts the size correction coefficient
table of the special 2 paper for the
discharge plate DC for each printing
side.
2-830-014 SepaDC:Mid:2nd *ENG
2-830-015 SepaDC:Low:1st *ENG
2-830-016 SepaDC:Low:2nd *ENG
[SP 2:Ed-Env.Cor] DFU
2-830-017 SepaDC:Mid:1st *ENG [1 to 100 / 30 / 1 /step]
Adjusts the size correction coefficient
table of the special 2 paper for the
discharge plate DC (leading and traiing
edges) for each printing side.
2-830-018 SepaDC:Mid:2nd *ENG
2-830-019 SepaDC:Low:1st *ENG
2-830-020 SepaDC:Low:2nd *ENG
2851 [Special 3: Bias]
Adjusts the DC voltage of the discharge plate for special paper 3.
Low: 85 mm/sec
5. System Maintenance Reference
388
