2871 [SP 3:LE Correct] DFU
Special 3 Paper: Leading Edge Correction
Adjusts the correction to the paper transfer roller current at the paper leading edge in
each mode. SP2852 and SP2857 are multiplied by these SP values.
Low: 85 mm/sec
• The paper leading edge area can be adjusted with SP2872.
2-871-003 PTr: Low: 1st *ENG [0 to 995 / 100 / 5%/step]
2-871-004 PTr: Low: 2nd *ENG
2-871-007 SepaDC:Low:1st *ENG
2-871-008 SepaDC:Low:2nd *ENG
2872 [SP 3:SW Tmng:LE] DFU
Adjusts the bias/ voltage switch timing of the paper transfer roller/ discharge plate at
the paper leading edge between the erase margin area and the image area.
Low: 85 mm/sec
2-872-003 PTr: Low : 1st *ENG [0 to 50 / 0 / 2 mm/step]
2-872-004 PTr: Low : 2nd *ENG
2-872-007 SepaDC:Low:1st *ENG
2-872-008 SepaDC:Low:2nd *ENG
2873 [SP 3:TE Correct] DFU
Special 3 Paper: Trailing Edge Correction
Adjusts the correction to the paper transfer roller current for the paper trailing edge in
each mode. SP2852 and SP2857 are multiplied by these SP values.
Low: 85 mm/sec
• The paper trailing edge area can be adjusted with SP2874.
Engine SP Mode Tables - SP2000
393
