2-873-003 PTr: Low: 1st *ENG [0 to 995 / 100 / 5%/step]
2-873-004 PTr: Low: 2nd *ENG
2-873-007 SepaDC:Low:1st *ENG
2-873-008 SepaDC:Low:2nd *ENG
2874 [SP 3:SW Tmng:TE] DFU
Adjusts the bias/voltage switch timing of the paper transfer roller/discharge plate at
the paper trailing edge between the erase margin area and the image area.
Low: 85 mm/sec
2-874-003 PTr: Low : 1st *ENG [0 to 50 / 0 / 2 mm/step]
2-874-004 PTr: Low : 2nd *ENG
2-874-007 SepaDC:Low:1st *ENG
2-874-008 SepaDC:Low:2nd *ENG
2880 [SP 3: EnvCor] DFU
Low: 85 mm/sec
2-880-015 SepaDC:Low:1st *ENG [1 to 100 / 30 / 1 /step]
Adjusts the size correction coefficient
table of the special 3 paper for the
discharge plate DC for each printing
side.
2-880-016 SepaDC:Low:2nd *ENG
[SP 3:Ed-Env.Cor] DFU
2-880-019 SepaDC:Low:1st *ENG [1 to 100 / 30 / 1 /step]
Adjusts the size correction coefficient
table of the special 3 paper for the
discharge plate DC (leading and traiing
edges) for each printing side.
2-880-020
SepaDC:Low:2nd
*ENG
2904 [Reverse Time] DFU
Adjusts the time for how long the image transfer belt motor reverses after job end.
2-904-003 Transfer All *ENG [0 to 800 / 70 / 10 msec/step]
5. System Maintenance Reference
394
