5-849-002 Print Determines whether the installation date is printed
on the printout for the total counter.
[0 or 1 / 1 / - /step]
0: OFF (No Print)
1: ON (Print)
5-849-003 Total Counter -
5851 [Bluetooth Mode]
Sets the operation mode for the Bluetooth Unit. Press either key.
[0:Public] [1: Private]
5856 [Remote ROM Update]
Allows the technician to upgrade the firmware using a local port (IEEE1284) when
updating the remote ROM.
5-856-002 Local Port *CTL [0 to 1 / 0 / 1/step]
0: Disable
1: Enable
5857 [Save Debug Log]
5-857-001 On/Off *CTL [0 or 1 / 0 / 1/step]
0: OFF
1: ON
Switches the debug log feature on and off.
The debug log cannot be captured until this
feature is switched on.
5-857-002 Target(2:HDD 3:SD) *CTL [1 to 3 / 2 / 1/step]
1: IC card
2: HDD
3: SD card
Selects the storage device to save debug
logs information.
Engine SP Mode Tables - SP5000
461
