• The length of time needed to transfer the debug log data can be affected by the type and
format of the SD card. Formatting the SD card with Panasonic SD Formatter (freeware) is
recommended.
The approximate time required for the transfer of the following debug logs are:
• Controller (GW): 2 to 20 min.
• Engine debut log: 2 min.
• Operation: 2 to 20 minutes
7. Make sure that the SD card access LED is off, then remove the SD card.
If you see the "Failed" message, remove the SD card, cycle the machine off/on, and then repeat
this procedure from Step 2.
Debug logs are saved with the following file names.
Debug Log Filename Format
Controller(GW) /LogTrace/machine no./watching/yyyymmdd_hhmmss_unique ID.gz
Engine /LogTrace/machine number/engine/yyyymmddhhmmss.gz
Operation Panel /LogTrace/machine no./opepanel/yyyymmdd_hhmmss.tar.gz
Capturing the Debug Logs
557
