Ricoh Aficio SP C440DN User Manual

No.
Sensor Name/
Sensor Board Name
Active
CN No./
Pin No.
Condition Symptom
22
Paper Height Sensor
1/2
A
CN116/A6,
A9
Open
Remaining paper volume
is wrong.
Shorted
23 Paper Feed Sensor L CN129/4
Open Paper is not detected.
Shorted • Paper is detected.
• Jam A
24
Vertical Transport
Sensor
L CN129/7
Open • Paper is not
detected.
• Jam A
Shorted • Paper is detected.
• Jam A
25 Paper Lift Sensor H CN129/13
Open SC501
Shorted SC501
26 Paper End Sensor L CN129/10
Open • Paper end is not
detected.
• Jam A
Shorted • Paper end is
detected.
27
Fusing Entrance
Sensor
L CN126/A14
Open Paper jam is not
detected.
Shorted • Paper jam is
detected.
• Jam B
28
Duplex Entrance
Sensor
L CN126/A8
Open • Paper is not
detected.
• Jam Z
Shorted • Paper is detected.
• Jam Z
Electrical Component Defects
631

Ricoh Aficio SP C440DN Specifications

General

Print Technology	Laser
Resolution	1200 x 1200 dpi
Processor	533 MHz
Supported Operating Systems	Windows, Mac OS, Linux
Weight	32 kg
Print Speed	Up to 42 ppm
Monthly Duty Cycle	150000 pages
Paper Input Capacity	650 sheets
Connectivity	USB 2.0
Paper Sizes	A4, A5, A6, B5, Legal, Letter, Executive
Dimensions	40 cm x 52.85 cm x 42 cm
