Ricoh Aficio SP C440DN User Manual

No.
Sensor Name/
Sensor Board Name
Active
CN No./
Pin No.
Condition Symptom
29 Duplex Exit Sensor L CN126/A11
Open • Paper is not
detected.
• Jam Z
Short • Paper is detected.
• Jam Z
30
By-pass Paper End
Sensor
L CN126/B8
Open • Paper end is not
detected.
• Jam A
Shorted • Paper end is
detected.
31 Inverter Sensor L CN126/A2
Open • Paper is not
detected.
• Jam Z
Shorted • Paper is detected.
• Jam Z
32 Fusing Exit Sensor H CN104/12
Open
Jam C
Shorted
Optional Paper Feed Unit
No.
Sensor Name/
Sensor Board Name
Active
CN No./
Pin No.
Condition Symptom
1 Paper Size Sensor A
CN103/1, 2,
3
Open
Paper size error
Shorted
2 Tray Set Sensor L CN103/7
Open Tray is not detected.
Shorted Tray is detected.
3
Paper Height Sensor
1/2
A
CN101/10,
13
Open
Remaining paper volume
is wrong.
Shorted
6. Troubleshooting
632

Ricoh Aficio SP C440DN Specifications

General

Print Technology	Laser
Resolution	1200 x 1200 dpi
Processor	533 MHz
Supported Operating Systems	Windows, Mac OS, Linux
Weight	32 kg
Print Speed	Up to 42 ppm
Monthly Duty Cycle	150000 pages
Paper Input Capacity	650 sheets
Connectivity	USB 2.0
Paper Sizes	A4, A5, A6, B5, Legal, Letter, Executive
Dimensions	40 cm x 52.85 cm x 42 cm
