FX-20
9. Set Fail-safe (Modulation MULTI)
IIn 7 CH operation, the Failsafe Function is assigned to chan-
nel 3 (throttle) and cannot be changed. In „MULTI“ operation,
channels 1-8 may all be set libary.
HOLD-Mode: The receiver stores the last „good“ signal and
the servos maintains their last commanded position until the
interference stops.
This is factory pre-set for the Throttle channel and is, due to
safety reasons, only recommended to be used on servo chan-
nels (MULTI operation)!
Changing channel 3 Throttle to Fail-safe Position (F/S):
(F/S) Fail-Safe: Here all the servos will move to a transmitter
pre-programmed position, which is then stored by the recei-
ver.
For safety, it is recommended that, Failsafe position for Drive
Motors is set to OFF or Idle.
Program Motor Con-
trol or Switch to its respective (OFF) position!
Programming example
66
1x
1x
1x
1Sek.
