Remote Control
R&S
®
RTM20xx
426User Manual 1317.4726.02 ─ 01
Parameters:
<DataCondition> EQUal | NEQual | GTHan | LTHan
*RST: EQ
TRIGger:A:LIN:DLENgth <DataLength>
Defines the length of the data pattern - the number of bytes in the pattern.
The command is relevant if TRIGger:A:LIN:TYPE is set to IDDT.
Parameters:
<DataLength> Range: 1 to 8
Increment: 1
*RST: 1
Default unit: Byte
LIN - Decode Results
BUS<b>:LIN:FCOunt?....................................................................................................426
BUS<b>:LIN:FRAMe<n>:DATA?.....................................................................................426
BUS<b>:LIN:FRAMe<n>:STATus?..................................................................................427
BUS<b>:LIN:FRAMe<n>:STARt?....................................................................................427
BUS<b>:LIN:FRAMe<n>:STOP?.....................................................................................427
BUS<b>:LIN:FRAMe<n>:CSSTate?.................................................................................428
BUS<b>:LIN:FRAMe<n>:CSValue?.................................................................................428
BUS<b>:LIN:FRAMe<n>:IDPValue?................................................................................428
BUS<b>:LIN:FRAMe<n>:IDSTate?..................................................................................429
BUS<b>:LIN:FRAMe<n>:IDValue?..................................................................................429
BUS<b>:LIN:FRAMe<n>:SYSTate?.................................................................................429
BUS<b>:LIN:FRAMe<n>:SYValue?.................................................................................430
BUS<b>:LIN:FRAMe<n>:VERSion?.................................................................................430
BUS<b>:LIN:FRAMe<n>:BCOunt?..................................................................................430
BUS<b>:LIN:FRAMe<n>:BYTE<o>:STATe?.....................................................................431
BUS<b>:LIN:FRAMe<n>:BYTE<o>:VALue?.....................................................................431
BUS<b>:LIN:FCOunt?
Returns the number of received frames of the active LIN bus.
Suffix:
<b>
.
1..4
Selects the bus.
Return values:
<FrameCount> Total number of decoded frames.
Usage: Query only
BUS<b>:LIN:FRAMe<n>:DATA?
Returns the data bytes of the specified frame.
Command Reference
