Roland LEC-540 - Media Take-Up System

1
Machine Highlights
Part Names and Functions
9
Media Take-up System
AUTO switch
This makes the direction
of rotation for take-up
during printing change
automatically.
MANUAL switch
You use this when
you want to operate
the media take-up
system manually.
Take-up cable
This is connected
to the printer.
Take-up unit
This takes up media.
Dancer roller
This maintains uniform
tension for media.
