Take-up
System
Use Conditions of the Media Take-up System
When Performing Output without Pullback Movement (or When [TU] Is Selected)
In using the media take-up system to perform output without pullback move-
ment, select [TU] of the [SETUP SHEET] menu.
When [TU] is selected, follow the below instructions.
Never pull the media with excessive force.
If the media is pulled forcedly, it may result in interruptions during output or inaccuracy of output locations.
When using the media take-up system, to avoid pulling media with undue force, be sure to observe the fol-
lowing points.
Set the [PREFEED] setting-menu item to "DISABLE."
Never operate the MANUAL switch for the take-up unit when the loading lever is pulled back.
Never press
to pull the media back.
Be sure to set the base point when the media is moved forward by pressing
after the setting of
the media is completed.
When the computer has an activated setting to pull back the media after output, disable it.
Set 120mm or more on the computer for the margin from the output end location to the next output start
location (or the space between the pages).
Do not perform output involving the pullback movement, such as the cutting movement or the pulling-
back printing.
When Performing Continuous Printing of Two or More Pages
When you're performing continuous printing and take-up for two or more pages, give attention to the fol-
lowing points.
If the setting to execute automatic cuto of the media can be made on the computer, then turn this setting
o. Making the setting on the computer to execute automatic cuto of the media results in media cuto
after each page is printed. Take up quits as soon as the media is cut o.
SETUP SHEET
TU
To Next Page
