36
2
Basic
Operation
Loading Media
Loading Roll Media
CAUTION
Load roll media correctly.
Otherwise the media may fall and cause injury.
CAUTION
Roll media weighs about 30 kg (66 lb.). Handling roll media is an opera-
tion that must be performed by two persons or more, and care must be
taken to prevent falls.
Attempting to lift heavy media in a manner that taxes your strength may cause
physical injury. Also, if dropped, such items may cause injury.
CAUTION
Never load media that weighs more than 30 kg (66 lb.) .
The machine may fail to withstand the weight and tip over or cause the media
to fall.
CAUTION
When performing printing, be sure to attach the rear cover.
When the rear cover is not installed, ultraviolet light can escape from the ma-
chine more easily.
1.
Install the media to the media holder.
Note: The media holder of this machine is exclusive use for the media of paper tube (core) inner diameter 3
inches. To use 2 inches media, the optional media anges are required. For information about optional items,
contact your authorized dealer or us.
Open the front cover.
Move the right and left media clamps to each end.
Put the rear table back in place.
Front cover
Media clamp
Media clamp
Rear table
To Next Page
