191
8
Main
Specications
Specications
LEC-540
Printing/cutting method Piezo ink-jet method/media-moving method
Acceptable me-
dia
Width 260 to 1371 mm (10.2 to 54 in.)
Thickness Maximum 1.0 mm (39 mil) with liner, for printing
Maximum 0.4 mm (16 mil) with liner and 0.22 mm (9 mil) without
liner, for cutting
Roll outer diameter Maximum 210 mm (8.3 in.)
Roll weight Maximum 30 kg (66 lb.)
Core diameter (*1) 76.2 mm (3 in.) or 50.8 mm (2 in.)
Printing/cutting width (*2) Maximum 1346 mm (53 in.)
Ink cartridges Types ECO-UV, ECO-UVS
Colors ECO-UV (Cyan, Magenta, Yellow, Black, White, Gloss)
ECO-UVS (Cyan, Magenta, Yellow, Black, White)
Ink-curing unit Dual UV LED Lamp
Printing resolution (dots per inch) Maximum 1440 dpi
Acceptable tool Roland CAMM-1 series compatible
Cutting speed 10 to 600 mm/s (10 to 300 mm/s in media-feed direction)
Blade force 30 to 300 gf
Blade oset compensation 0.000 to 1.500 mm (0 to 0.0591 in.)
Software resolution (when cutting) 0.025 mm/step (0.000984 in./step)
Distance accuracy (when printing) (*3)
(*4) (*9)
Error of less than ±0.3% of distance traveled, or ±0.3 mm, which-
ever is greater
Distance accuracy (when cutting) (*3) (*9) Error of less than ±0.4% of distance traveled, or ±0.3 mm, which-
ever is greater
When distance correction has been performed (when the setting
for [CUTTING MENU] - [CALIBRATION] has been made): Error of
less than ±0.2% of distance traveled, or ±0.1 mm, whichever is
greater
Repetition accuracy (when cutting) (*3)
(*5) (*9)
±0.1 mm or less
Alignment accuracy for printing and cut-
ting (*3) (*6) (*9)
±0.5 mm or less
Alignment accuracy for printing and cut-
ting when reloading media (*3) (*7) (*9)
Error of less than ±0.5% of distance traveled, or ±3 mm, whichever
is greater
Media take-up
system
Roll outer diameter Maximum210 mm (8.3 in.)
Roll weight Maximum 30 kg (66 lb.)
Interface Ethernet (10BASE-T/100BASE-TX, automatic switching)
Power-saving function Automatic sleep feature
Power requirements AC 100 to 240 V ±10%, 5.5 A, 50/60 Hz
Power consump-
tion
During operation 490 W
Sleep mode 15.3 W
Acoustic noise
level
During operation 64 dB (A) or less
During standby 40 dB (A) or less
Dimensions (with stand) When not using front table : 2925 (W) × 910 (D) × 1260 (H) mm
(115.2 (W) × 35.8 (D) × 49.6 (H) in.) (*8)
When using front table : 2925 (W) × 1120 (D) × 1260 (H) mm (115.2
(W) × 44.1 (D) × 49.6 (H) in.)
Weight (with stand) 225 kg (496 lb.)
Environment Power on Temperature: 20 to 32ºC (68 to 90ºF) (22ºC [72˚F] or more recom-
mended) , Relative humidity: 35 to 80% (no condensation)
Power o Temperature: 5 to 40˚C (41 to 104˚F), Relative humidity: 20 to 80%
(no condensation)
Accessories Exclusive stands, power cord, blade, blade holder (XD-CH2), me-
dia clamps, replacement blade for separating knife, software RIP
(Roland VersaWorks) , User's Manual, etc.
To Next Page
