Use Conditions of the Media Take-up System
3
Take-up
System
88
Removing Taken-up Media
CAUTION
Removal of taken-up roll media from the unit is a task which must be
carried out by two or more persons.
If dropped, such items may cause injury.
Cut off the media.
P. 75, "Cutting Off the Media"
Support the paper tube to prevent it from falling.
Loosen the arm retaining screw and move the arm.
Detach the paper tube from the end caps.
Arm retaining screw
To Next Page
