4
Mainte-
nance
Replacing Consumable Parts
117
Replacing the Separating Knife
If the separating knife becomes dull, replace it with the included replacement knife
CAUTION
Be sure to perform operations as specied by these instructions, and
never touch any area not specied in the instructions.
Sudden movement of the machine may cause injury.
CAUTION
Never touch the tip of the blade with your ngers.
Doing so may result in injury.
1.
Replacing the Separating Knife.
Press .
Press several times until the screen shown on
the left appears.
Press
and then .
Press .
Press
twice.
Press .
The cutting carriage moves to a location where blade replacement is
possible, and then the screen shown in the gure appears.
Open the front cover.
Preparations are complete when this screen appears.
2.
Replace the separating knife.
Remove the separating knife.
Loosen the screw until it slips out.
Grasp the screw portion, and slowly pull
it out in the direction of the arrow. When do-
ing this, do not pull it back toward you.
To Next Page
