Use Conditions of the Media Take-up System
3
Take-up
System
84
Loading the Media onto the Media Take-up System
1.
Pass the media through the printer.
Move the dancer roller toward the rear.
Switch on the printer's sub power.
When selecting [TU] under the [SETUP SHEET] menu, be sure that the [PREFEED]
menu is set at [DISABLE].
P. 133, "Preventing Pulling of the Media with Undue Force When Performing Cutting Only"
Load the roll media onto the printer.
2.
Fasten the media to the paper tube.
When you attach the paper tube, insert it securely onto the end caps on the take-up unit. For information on
how to install it, refer to the Setup Guide.
[ To perform output without pullback movement ]
Press
to select "TU."
[ To perform output involving pullback movement ]
Press
and select [TU2].
Press .
The screen shown in the gure appears.
SETUP SHEET
TU
SETUP SHEET
TU2
LOAD SHEET
TO TAKE-UP
Dancer roller
To Next Page
