Use Conditions of the Media Take-up System
3
Take-up
System
85
Use to pull out the media until its leading edge reaches the paper tube.
You can adjust the length of the media in 10-millimeter steps by pressing . (To pull out media
continuously, hold down the key. )
Using adhesive tape, fasten the center and side edges of the media to the paper tube
(fasten a total of three locations).
Secure the center of the media in place while keeping the media stretched taut to
keep it free of slack.
While pulling the media from the center outward, fasten the left and right edges.
■ Take-up with outward curl
■ Take-up with inward curl
Paper tube
Adhesive tape
Paper tube
Adhesive tape
To Next Page
