Roland LEC-540 User Manual

Specications
8
Main Specications
192
*1
The media holder of this machine is exclusive use for the media of paper tube (core) inner diameter 3 inches.
To use 2 inches media, the optional media anges are required.
*2
The length of printing or cutting is subject to the limitations of the program.
*3
 Media type: Media specied by Roland DG Corp. (Cutting only)
 Temperature: 25°C (77°F), humidity: 50%
 Roll media must be loaded correctly.
 Applicable when all pinch rollers available to the media width are used.
 Side margins: 25 mm or more for both the left and right margins
 Front margin: 35 mm or more
 Excluding expansion/contraction of the media
 All correction or adjustment function of this machine has been made properly.
*4
 With Roland PET lm, print travel: 1 m
*5
 [PREFEED] menu item must be set to "ENABLE."
Range for assured repetition accuracy
 Length 3,000 mm
*6
 Provided that media length is under 3,000 mm
 Excludes the eects of slanted movement and of expansion and contraction of the media.
*7
 Data size: 1,000 mm in the media-feed direction, 1,346 mm in the carriage-movement direction.
 No lamination.
 Automatic detection of crop marks at 4 points when media is reloaded.
 During cutting, [PREFEED] menu item must be set to "ENABLE."
 Excluding possible shift caused by expansion/contraction of the media and/or by reloading the media.
*8
During operation of the media take-up system, an operating range of approximately 80 millimeters back from
the front edge of the dancer roller is required.
*9
Applicable when neither the front table nor the rear table is used.
