M-48 Control

200

Connection Producing Noise (Not OK)

S-4000D

REAC A

MASTER

M-48

M-5000 96kHz

REAC MASTER

S-4000S-4000

REAC SLAVE

/40ch/96kHz

Connection Producing No Noise 1 (OK)

Set the system’s sampling rate at 48 kHz.

S-4000D

REAC A

MASTER

M-48

M-5000 48kHz

REAC MASTER

S-4000S-4000

REAC SLAVE

/40ch/48kHz
