Roland VR-6HD

101
Menu List
Menu item Value (bold text: default value) Explanation
DELAY
0.0–500msec
(0–25.0/29.9/30.0frame)
Adjusts the delay time of the audio.
Eect Outputs audio with a delay.
REVERB SEND
0–127 Adjusts the amount of audio sent to reverb.
MAIN BUS
This congures the MAIN bus.
SEND
OFF, ON When this is “ON”, audio is sent to the MAIN bus.
AUX 1 BUS
This congures the AUX 1 bus.
SEND LEVEL
-INF–10.0dB These parameters adjust the amount of audio sent to the AUX 1 bus.
SEND POINT
DRY
Sends the source audio with no eects applied.
PRE FADER
Sends the eect-applied audio.
The send volume is constant, regardless of the volume (INPUT LEVEL).
POST FADER
Sends the eect-applied audio.
The send volume can be changed by adjusting the volume (INPUT LEVEL).
AUX 2 BUS
This congures the AUX 2 bus.
SEND LEVEL
-INF–10.0dB These parameters adjust the amount of audio sent to the AUX 2 bus.
SEND POINT
DRY
Sends the source audio with no eects applied.
PRE FADER
Sends the eect-applied audio.
The send volume is constant, regardless of the volume (INPUT LEVEL).
POST FADER
Sends the eect-applied audio.
The send volume can be changed by adjusting the volume (INPUT LEVEL).
HIGH PASS FILTER 80Hz
OFF, ON
Turns the high-pass lter on/o.
Eect Cuts o unneeded low-band audio. The cuto frequency is 80 Hz.
NOISE GATE
OFF, ON
Turns the noise gate on/o.
Eect
Eliminates audio that is lower than the specied threshold level. This is eective when the
noise that you want to remove is separate from the audio that you want to keep, and can be
used to remove hiss or other noise that is heard during periods of silence.
THRESHOLD
-80–-48–0dB
Species the level used as the threshold for removing audio. Audio below the level set
here is removed.
RELEASE
30–500–5000msec
Adjusts the length of time until the audio is fully attenuated after audio falls below the
threshold.
DE-ESSER
OFF, ON
Turns the de-esser on/o.
Eect
Reduces sibilant noise (the sounds you hear when pronouncing “s” words and other hissing
sounds).
SENS
0–80–100 Adjusts the sensitivity with which sibilants are detected.
DEPTH
0–64–100 Adjusts the intensity of the eect.
COMPRESSOR
OFF, ON
Turns the compressor on/o.
Eect
Audio that exceeds the specied threshold level is compressed. This reduces the dierence
between the maximum volume and minimum volume, making the audio more comfortable
for listening
THRESHOLD
-50–-8–0dB
Species the level used as the threshold at which the compressor is applied.
Compression is applied to audio that exceeds the threshold.
RATIO
1.00:1, 1.12:1, 1.25:1, 1.40:1,
1.60:1, 1.80:1, 2.00:1, 2.50:1,
3.20:1, 4.00:1, 5.60:1, 8.00:1,
16.0:1, INF:1
Species the degree of compression applied to the audio. The state in which no
compression is applied is dened as “1”.
ATTACK
0–30–100msec Species the time until compression starts when audio exceeding the threshold is input.
RELEASE
30–250–5000msec Adjusts the length of time until compression ends after audio falls below the threshold.
MAKEUP GAIN
-40–0–40dB Adjusts the nal output volume level after applying the compressor.
EQUALIZER OFF, ON
Turns the equalizer on/o.
Eect
This is a 4-band parametric equalizer. It lets you shape the character of the sound by
boosting or cutting four frequency regions.
Hi GAIN -12.0–0.0–12.0dB Boosts or attenuates the high band.
Hi FREQUENCY 1.00–10.0–20.0kHz Adjusts the center frequency when changing the tone quality in the high band.
Hi-Mid GAIN -12.0–0.0–12.0dB Boosts or attenuates the high-midrange band.
Hi-Mid FREQUENCY 20Hz–2.00kHz–20.0kHz
Adjusts the center frequency when changing the tone quality in the high-midrange band.
Hi-Mid Q 0.5–1.0–16.0 Adjusts the width of the frequency band when boosting or attenuating high-midrange band.
Lo-Mid GAIN -12.0–0.0–12.0dB Boosts or attenuates the low-midrange band.
Lo-Mid FREQUENCY 20Hz–500Hz–20.0kHz Adjusts the center frequency when changing the tone quality in the low-midrange band.
Lo-Mid Q 0.5–1.0–16.0
Adjusts the width of the frequency band when boosting or attenuating low-midrange
band.
Lo GAIN -12.0–0.0–12.0dB Boosts or attenuates the low band.
Lo FREQUENCY 20Hz–100Hz–2.00kHz Adjusts the center frequency when changing the tone quality in the low band.
(*3) When “STEREO LINK” is “ON”, the [4]–[6] fader operations are disabled.
(*4) This can be set if “STEREO LINK” is “OFF”.
