43
Audio Operations
Adjusting the Volume Balance from the Mixer
Screen
The mixer screen on this unit’s display lets you adjust the various volumes
while checking their values.
1. Press the [MONITOR] button a number of times to select
AUDIO LEVEL.
The Audio Level screen appears.
Switch between pages
2. Touch the tabs at the top of the screen to switch to a page
from ALL to CUSTOM.
3. Drag the faders on the screen to adjust the volumes. (FADER
/ AUDIO IN / OTHERS / VIDEO IN / CUSTOM)
You can switch between content views by using the tabs at the top of
the screen.
Content
displayed
Explanation
ALL Audio levels for all input/output channels
FADER Sound sources assigned to faders
AUDIO IN Audio from AUDIO IN 1–7/8 jacks
OTHERS
Audio from USB STREAM connector, Bluetooth In,
audio player and video player
VIDEO IN Audio from VIDEO IN 1–6 connectors
CUSTOM
Custom settings. This lets you freely assign the
inputs and outputs.
