Other Functions
Using a Footswitch
You can use a footswitch connected to the CTL/EXP 1 and 2 jacks to control the VR-6HD with your foot. You can assign various functions to the footswitch.
1. [MENU] button
Ó
“REMOTE”
Ó
“CTL/EXP”
Ó
“CTL/EXP 1” or
“CTL/EXP 2”
Ó
select “CTL/EXP TYPE”, and press the [VALUE]
knob.
2. Set the connected device to “CTL A & CTL B” (the footswitch)
using the [VALUE] knob, and press the [VALUE] knob.
3. Use the [VALUE] knob to select CTL A or CTL B “CATEGORY”
and “VALUE”, and press the [VALUE] knob.
4. Use the [VALUE] knob to select the function that you want
to assign to CTL A or CTL B of the footswitch, and press the
[VALUE] knob.
ÁCATEGORY
Value Explanation
N/A No function is assigned.
PGM CH SELECT
Switches the video sent to the PGM bus.
PST CH SELECT
Switches the video sent to the PST bus.
AUX CH SELECT Switches the video sent to the AUX bus.
INPUT 1–6 ASSIGN Changes the video assigned to INPUT 1–6.
STILL OUTPUT
Pauses the normal output, and previews
or nal outputs a cut of the still image.
VIDEO PLAYER OUTPUT
Temporarily pauses the normal output,
and previews or nal outputs a cut of the
video player’s video signal.
PinP & KEY 1–2 SOURCE
Switches the video source of the inset
screen.
DSK SOURCE Switches the DSK video source.
BUTTON CONTROL
This works the same as when you press
the button selected in “VALUE”.
AUDIO INPUT MUTE
Turns the mute function on/o for the
input audio.
AUDIO OUTPUT MUTE
Turns the mute function on/o for the
output audio.
AUDIO INPUT SOLO
Turns the solo function on/o for the
input audio.
AUDIO OUTPUT SOLO
Turns the solo function on/o for the
output audio.
VOICE CHANGER Turns the voice changer function on/o.
AUTO MIXING Turns the auto mixing function on/o.
REVERB(MOMENTARY)
Reverb turns on only while you press the
footswitch.
REVERB(ALTERNATE) Turns reverb on/o.
OUTPUT FADE The nal output video fades in/out.
LOAD MEMORY Recalls a scene memory.
INPUT SCAN
Each time you press the footswitch, the
INPUT 1–6 video changes in order.
SCENE MEMORY SCAN
Each time you press the footswitch, scene
memories 1–32 are recalled in order.
PinP & KEY 1–2 SCAN
The PinP & KEY 1–2 inset screen videos
switch in order each time you press the
footswitch.
Value Explanation
DSK SCAN
The DSK caption video switches in order
each time you press the footswitch.
MACRO EXECUTE
Executes a macro (a series of recorded
operations).
SEQUENCER
When the sequencer function is on, this
works the same as when you press the
button selected in “VALUE”.
GPO (ONE SHOT) Outputs a control signal for 0.5 seconds.
GPO (ALTERNATE)
The control signal output is switched on/
o with each press of the footswitch.
ÁVALUE
Congures the detailed settings related to “CATEGORY”.
5. Press the [MENU] button to close the menu.
MEMO
¹ See “Connecting a Footswitch” (p. 9) for how to connect a
footswitch to this unit.
¹ If a single-pedal type footswitch such as the BOSS FS-5U is
connected using a phone cable (mono), the function assigned by
“CTL B” is enabled.
