Roland VR-6HD

123
Menu List
4: PinP/DSK
PinP & KEY 1–2
Menu item Value (bold text: default value) Explanation
TYPE
Species the type of PinP compositing.
PinP Composites the inset screen on top of the background video.
LUMINANCE WHITE KEY
A combination of PinP and luminance key (white).
Makes the white portions of the inset screen transparent, and composites the image with
the background.
LUMINANCE BLACK KEY
A combination of PinP and luminance key (black).
Makes the black portions of the inset screen transparent, and composites the image with
the background.
CHROMA KEY
A combination of PinP and chroma key.
Makes the specied key color portions of the inset screen transparent, and composites
the image with the background.
SOURCE
VIDEO 1–6, STILL 1–16, V.PLAYER, INPUT 1–6 Species the video source of the inset screen.
TIME 0.0–1.0–4.0sec Species the video transition time.
When TYPE = PinP
WINDOW Adjusts the inset screen.
POSITION H -50.0–-40.0–50.0% Adjusts the horizontal position of the inset screen.
POSITION V -50.0–-40.0–50.0% Adjusts the vertical position of the inset screen.
SIZE 0.0–35.0–100.0% Adjusts the size of the inset screen.
CROPPING H 0.0–100.0% Adjusts the horizontal size of the inset screen.
CROPPING V 0.0–100.0% Adjusts the vertical size of the inset screen.
SHAPE RECTANGLE, CIRCLE, DIAMOND Species the shape of the inset screen.
BORDER COLOR
WHITE, YELLOW, CYAN, GREEN, MAGENTA, RED,
BLUE, BLACK, SOFT EDGE
Species the color of the border for the inset screen.
When this is set to “SOFT EDGE”, the edge of the inset screen is blurred.
BORDER WIDTH 0–3–14 Adjusts the width of the border for the inset screen.
VIEW Adjusts the video that is shown in the inset screen.
POSITION H -50.0–0.0–50.0% Adjusts the horizontal position at which the inset screen is shown.
POSITION V -50.0–0.0–50.0% Adjusts the vertical position at which the inset screen is shown.
ZOOM 100–400% Adjusts the zoom of the video shown in the inset screen.
When TYPE = LUMINANCE WHITE KEY or LUMINANCE BLACK KEY
WINDOW Adjusts the inset screen.
POSITION H -50.0–-40.0–50.0% Adjusts the horizontal position of the inset screen.
POSITION V -50.0–-40.0–50.0% Adjusts the vertical position of the inset screen.
SIZE 0.0–35.0–100.0% Adjusts the size of the inset screen.
CROPPING H 0.0–100.0% Adjusts the horizontal size of the inset screen.
CROPPING V 0.0–100.0% Adjusts the vertical size of the inset screen.
VIEW Adjusts the video that is shown in the inset screen.
POSITION H -50.0–0.0–50.0% Adjusts the horizontal position at which the inset screen is shown.
POSITION V -50.0–0.0–50.0% Adjusts the vertical position at which the inset screen is shown.
ZOOM 100–400% Adjusts the zoom of the video shown in the inset screen.
KEY Adjusts the key.
KEY LEVEL
0–60–255 Adjusts the degree of extraction (transparency) for the key.
KEY GAIN
0–255 Adjusts the degree of edge blur (semi-transmissive region) for the key.
MIX LEVEL
0–255 Adjusts the key’s overall density (output level).
