Roland VR-6HD

132
Menu List
11: REMOTE
RC232
Menu item
Value (bold text: default
value)
Explanation
RS-232
These are the settings for transmitting/receiving RS-232 commands.
RS-232
OFF, ON When this is “ON”, RS-232 commands can be transmitted and received.
BAUDRATE
9600, 38400, 115200 Species the communication speed (bps) of the RS-232 connector.
TALLY/GPO
Menu item
Value (bold text: default
value)
Explanation
TALLY/GPO
These are settings for tally signals or control signals that are output from the TALLY/GPIO connector.
TEMPLATE
TALLY, GPO, TALLY/GPO
Selects a TALLY/GPO 1–16 settings template.
Press the [VALUE] knob to apply the template settings to “TALLY/GPO 1–16”.
TALLY/GPO 1–16
Assigns the tally signal to TALLY/GPIO connector pins 1–16.
PGM VIDEO IN 1–6 A tally signal is output when the video sent from the connector in question is the nal output.
PGM STILL 1–16 A tally signal is output when the still image in question is the nal output.
PGM VIDEO PLAYER A tally signal is output when the video signal from the video player is the nal output.
PGM INPUT 1–6
A tally signal is output when the nal output video is selected using the VIDEO SWITCHER button in
question (the button lights up red).
PST VIDEO IN 1–6 A tally signal is output when the video sent from the connector in question is the preview output.
PST STILL 1–16 A tally signal is output when the still image in question is the preview output.
PST VIDEO PLAYER A tally signal is output when the video signal sent from the video player is the preview output.
PST INPUT 1–6
A tally signal is output when the preview output video is selected using the VIDEO SWITCHER button in
question (the button lights up green).
Assigns the GPO to TALLY/GPIO connector pins 1–16.
GPO 1–16 A control signal is output when you press the footswitch or assign a GPO output function to a GPI pin.
