Roland VR-6HD

142
Appendix
Main Specications
Ã
Video
Video Processing 4:2:2 (Y/Pb/Pr), 8-bit
Number of Video
Channels
6 channels
Input Connectors VIDEO IN 1–6
HDMI type A x 6
* HDCP Supported, Multi-format Supported
Output Connectors
VIDEO OUT 1–3
HDMI type A x 3
* HDCP Supported
USB STREAM USB Type-C®
Video Input Formats VIDEO IN 1–6
Frame Rate
59.94 Hz, 60 Hz 50 Hz
480/59.94i 480/59.94p 576/50i 576/50p
720/59.94p 720/50p
1080/59.94i 1080/59.94p 1080/50i 1080/50p
1080/60p 1080/25p
1080/29.97p 1080/30p 1080/23.98p 1080/24p
1080/23.98p 1080/24p VGA (640×480/60 Hz)
VGA (640×480/60 Hz) SVGA (800×600/60 Hz)
SVGA (800×600/60 Hz) XGA (1024×768/60 Hz)
XGA (1024×768/60 Hz) WXGA (1280×800/60 Hz)
WXGA (1280×800/60 Hz) SXGA (1280×1024/60 Hz)
SXGA (1280×1024/60 Hz) FWXGA (1366×768/60 Hz)
FWXGA (1366×768/60 Hz) SXGA+ (1400×1050/60 Hz)
SXGA+ (1400×1050/60 Hz) UXGA (1600×1200/60 Hz)
UXGA (1600×1200/60 Hz) WUXGA (1920×1200/60 Hz)
WUXGA (1920×1200/60 Hz)
* The refresh rate is the maximum value of each resolution.
* Conforms to CEA-861-E,VESA DMT Version 1.0 Revision 11.
* 1920 x 1200/60 Hz: Reduced blanking
* The input interlaced video signal is converted to progressive video signal by internal processing.
Video Output Formats
VIDEO OUT 1–3
Output Format
Frame Rate
59.94 Hz 60 Hz 50 Hz
720p 720/59.94p 720/60p 720/50p
1080i 1080/59.94i 1080/60i 1080/50i
1080p 1080/59.94p 1080/60p 1080/50p
Output Format
Frame Rate
29.97 Hz 30 Hz 25 Hz 23.98 Hz 24 Hz
1080p 1080/29.97p 1080/30p 1080/25p 1080/23.98p 1080/24p
USB STREAM
Frame Rate (USB STREAM)
59.94 Hz 60 Hz 29.97 Hz 30 Hz
1080/59.94p 1080/60p 1080/29.97p 1080/30p
720/59.94p 720/60p 720/29.97p 720/30p
640×480/59.94p 640×480/60p 640×480/29.97p 640×480/30p
Frame Rate (USB STREAM)
50 Hz 25 Hz 23.98 Hz 24 Hz
1080/50p 1080/25p 1080/23.98p 1080/24p
720/50p 720/25p 720/23.98p 720/24p
640×480/50p 640×480/25p 640×480/23.98p 640×480/24p
* Uncompressed format (YUY2) and Compressed format (Motion JPEG) supported.
