Roland VR-6HD

99
Menu List
2: AUDIO
AUDIO INPUT
Menu item Value (bold text: default value) Explanation
AUDIO IN 1, 2
AUDIO IN 1/2 (LINKED)
Adjusts the audio that is input from the AUDIO IN 1 and 2 jacks.
“AUDIO IN 1/2 (LINKED)” is shown when “STEREO LINK” is “ON”.
ANALOG GAIN
0–68dB Adjusts the input gain (sensitivity) in the analog domain.
DIGITAL GAIN
-42.0–0.0–42.0dB
Adjusts the input gain (sensitivity) in the digital domain (after conversion from analog to digital).
INPUT LEVEL
-INF–0.0–10.0dB
Adjusts the input volume.
This can also be adjusted from the [1] [2] faders. (*8)
INPUT MUTE
OFF, ON Turns the mute function on/o. When this is “ON”, the input audio is temporarily silenced.
PHANTOM +48V
OFF, ON
Turns the phantom power on/o. When this is “ON”, phantom power is supplied via the
AUDIO IN jacks (XLR).
* Changing “STEREO LINK” settings automatically turns “PHANTOM +48V” settings “OFF”.
PAN (*9)
LEFT–CENTER–RIGHT Adjusts the stereo position (pan).
STEREO LINK
OFF, ON
Turns the stereo link function on/o. When this is “ON”, AUDIO IN 1 and 2 are linked, and
operate as a stereo channel.
* When stereo link is turned on, the settings of AUDIO IN 1 are applied to AUDIO IN 2.
SOLO
OFF, ON
Turns the solo function on/o. Only the audio for which this is “ON” is heard in the headphones.
* The solo function applies to the headphone output. It does not aect output other than the
headphones.
DELAY
0.0–500msec
(0–25.0/29.9/30.0frame)
Adjusts the delay time of the audio.
Eect Outputs audio with a delay.
REVERB SEND
0–127 Adjusts the amount of audio sent to reverb.
MAIN BUS
This congures the MAIN bus.
SEND
OFF, ON When this is “ON”, audio is sent to the MAIN bus.
AUX 1 BUS
This congures the AUX 1 bus.
SEND LEVEL
-INF–10.0dB These parameters adjust the amount of audio sent to the AUX 1 bus.
SEND POINT
DRY
Sends the source audio with no eects applied.
PRE FADER
Sends the eect-applied audio.
The send volume is constant, regardless of the volume (INPUT LEVEL).
POST FADER
Sends the eect-applied audio.
The send volume can be changed by adjusting the volume (INPUT LEVEL).
AUX 2 BUS
This congures the AUX 2 bus.
SEND LEVEL
-INF–10.0dB These parameters adjust the amount of audio sent to the AUX 2 bus.
SEND POINT
DRY
Sends the source audio with no eects applied.
PRE FADER
Sends the eect-applied audio.
The send volume is constant, regardless of the volume (INPUT LEVEL).
POST FADER
Sends the eect-applied audio.
The send volume can be changed by adjusting the volume (INPUT LEVEL).
HIGH PASS FILTER 80Hz
OFF, ON
Turns the high-pass lter on/o.
Eect Cuts o unneeded low-band audio. The cuto frequency is 80 Hz.
ECHO CANCELLER
OFF, ON
Turns the echo canceller on/o.
Eect
Suppresses the voice echo that can occur when using a web conferencing system that
includes a speaker and mic.
DEPTH
1–5–10 Adjusts the depth of the echo canceller.
ANTI-FEEDBACK
OFF, ON
Turns the anti-feedback on/o.
Eect Suppresses audio feedback.
NOISE GATE
OFF, ON
Turns the noise gate on/o.
Eect
Eliminates audio that is lower than the specied threshold level. This is eective when the
noise that you want to remove is separate from the audio that you want to keep, and can be
used to remove hiss or other noise that is heard during periods of silence.
THRESHOLD
-80–-48–0dB
Species the level used as the threshold for removing audio. Audio below the level set
here is removed.
RELEASE
30–500–5000msec
Adjusts the length of time until the audio is fully attenuated after audio falls below the
threshold.
DE-ESSER
OFF, ON
Turns the de-esser on/o.
Eect
Reduces sibilant noise (the sounds you hear when pronouncing “s” words and other hissing
sounds).
SENS
0–80–100 Adjusts the sensitivity with which sibilants are detected.
DEPTH
0–64–100 Adjusts the intensity of the eect.
