Roland VR-6HD

98
Menu List
VIDEO OUTPUT
Menu item Value (bold text: default value) Explanation
VIDEO OUT 1–3 Adjusts the video that is output from the VIDEO OUT 1–3 connectors.
OUTPUT STATUS —
Shows the format and an HDCP signal presence. If there is no connection, “NOT CONNECTED”
is shown.
COLOR SPACE
YPbPr (4:4:4), YPbPr (4:2:2), RGB
(0–255), RGB (16–235)
Species the color space.
DVI-D/HDMI SIGNAL HDMI, DVI-D Species the type of output signal.
EXTERNAL REC
CONTROL
OFF, ON
Turns the External Rec control on/o. When this is “ON”, REC START/STOP commands can be
sent to a recorder that supports REC control functionality.
* To use the external REC control function, you must assign the video recording start/stop functions to a
USER button on the dashboard.
BRIGHTNESS -64–0–63 Adjusts the brightness.
CONTRAST -64–0–63 Adjusts the contrast.
SATURATION -64–0–63 Adjusts the saturation.
RED -64–0–63 Adjusts the red level.
GREEN -64–0–63 Adjusts the green level.
BLUE -64–0–63 Adjusts the blue level.
USB OUT
Adjusts the video that is output from the USB STREAM connector.
* You can edit the USB output video format and compression method from the livestreaming app or other app used at the output destination.
OUTPUT STATUS —
Indicates whether the connection uses USB 2.0 (HIGH SPEED) or USB 3.0 (SUPER SPEED).
If not connected to a computer, this indicates “NOT CONNECTED”.
* When “HDCP” in the SYSTEM menu is “ON”, “HDCP MASKED” is displayed, and video/audio is not
outputted from the USB STREAM connector.
OUTPUT FORMAT
Sets the output destination formats that can be selected from the livestreaming app.
YUY2 & MJPEG YUY2 and Motion JPEG are selectable.
YUY2 Only YUY2 is selectable.
CONNECTION RESET EXEC
Reconnects the computer and the VR-6HD when the video is garbled or when operation is
otherwise unstable.
FREEZE
Menu item
Value (bold text: default
value)
Explanation
FREEZE OFF, ON Turns the freeze function on/o. When this is “ON”, the input video is temporarily frozen.
TYPE
Species the operation mode for freezes.
ALL Freezes all video that is being input.
SELECT Freezes only the specied input video.
VIDEO 1–6 (*4) DISABLE, ENABLE
For each input, species whether the freeze function is enabled (ENABLE) or disabled
(DISABLE).
(*4) This can be set if “TYPE” is “SELECT”.
