Menu List
LAYER SETTINGS
Menu item Value (bold text: default value) Explanation
PROGRAM
PinP & KEY 1–2 DISABLE, ENABLE
Sets whether each layer is displayed (ENABLE) or hidden (DISABLE) in the nal output
video.
DSK DISABLE, ENABLE
SUB PROGRAM
PinP & KEY 1–2 DISABLE, ENABLE
Sets whether each layer is displayed (ENABLE) or hidden (DISABLE) in the SUB PROGRAM
bus video.
DSK DISABLE, ENABLE
AUX
PinP & KEY 1–2 OFF, PGM SYNC, ON
Sets whether each layer in the AUX bus video is shown (ON), synced with PGM (PGM SYNC)
or hidden (OFF).
DSK OFF, PGM SYNC, ON
VIDEO OUTPUT ASSIGN
Menu item Value (bold text: default value) Explanation
VIDEO OUT 1–3
Species the video bus that is assigned to the VIDEO OUT 1–3 connectors.
PROGRAM
Final output video. This is the default setting for “VIDEO OUT 1”.
SUB PROGRAM
SUB PROGRAM bus video
PREVIEW
Preview output video. This is the default setting for “VIDEO OUT 2”.
AUX
AUX bus video
MULTI-VIEW
Multi-view. This is the default setting for “VIDEO OUT 3”.
STILL-VIEW Still images loaded into the unit (shown as 16 separate sections on the screen)
USB OUT
Species the video bus that is assigned to the USB STREAM connector.
PROGRAM
Final output video.
SUB PROGRAM
SUB PROGRAM bus video
PREVIEW
Preview output video.
AUX
AUX bus video
MULTI-VIEW
Multi-view.
STILL-VIEW Still images loaded into the unit (shown as 16 separate sections on the screen)
STREAM/RECORD
Species the video bus that is assigned to the DIRECT STREAM port.
PROGRAM
Final output video.
SUB PROGRAM
SUB PROGRAM bus video
PREVIEW
Preview output video.
AUX
AUX bus video
MULTI-VIEW
Multi-view.
STILL-VIEW Still images loaded into the unit (shown as 16 separate sections on the screen)
LCD MONITOR
Species the video bus to which this unit’s display is assigned.
PROGRAM
Final output video.
SUB PROGRAM
SUB PROGRAM bus video
PREVIEW
Preview output video.
AUX
AUX bus video
MULTI-VIEW
Multi-view.
STILL-VIEW Still images loaded into the unit (shown as 16 separate sections on the screen)
AUDIO LEVEL Level meters for each channel
AUX SOURCE
VIDEO 1–6, STILL 1–16, V.PLAYER,
INPUT 1–16
Selects the video that is sent to the AUX bus.
When the mode is “AUX”,
you can also use the VIDEO SWITCHER [1]–[6] buttons to select the video signal that’s sent
to the AUX bus.
