Roland VR-6HD

137
Menu List
14: DASHBOARD
Menu item Value (bold text: default value) Explanation
LCD ASSIGN
LCD ASSIGN A, B
N/A Hidden
CLOCK Shows the analog/digital clock.
STREAM/RECORD STATUS 1
Shows the streaming/video recording status.
CATEGORY VALUE Explanation
––
START/STOP
Starting/stopping the livestream or video
recording
STREAM/RECORD STATUS 2 Shows the streaming/video recording status.
USER BUTTON1/2,
USER BUTTON 3/4
Touch the screen to execute the set function.
CATEGORY VALUE Explanation
N/A –– No function is assigned.
FREEZE –– Turns the freeze function on/o.
AUTO SWITCHING –– Turns the auto switching function on/o.
INPUT ASSIGN INPUT 1–6
Each time you press a button, the video source
assigned to the specied VIDEO SWITCHER
button switches in order as follows: VIDEO IN
1–6
Ó
STILL 1–16.
STILL OUTPUT STILL 1–16
Pauses the normal output, and previews or nal
outputs a cut of the still image.
VIDEO PLAYER OUTPUT ––
Temporarily pauses the normal output, and
previews or nal outputs a cut of the video
player’s video signal.
SCENE MEMORY MEMORY 1–32 Recalls a scene memory.
INPUT SCAN
NORMAL
Each time you press a button, the nal output
switches from INPUT 1–6 in sequential order.
REVERSE
Each time you press a button, the nal output
switches in reverse order from INPUT 6 through 1.
MEMORY SCAN
NORMAL
Each time you press a button, scene memories
1–32 are recalled in sequential order.
REVERSE
Each time you press a button, scene memories
are recalled in reverse order from 32 through 1.
PinP & KEY 1–2 SCAN
NORMAL
Each time you press a button, the PinP & KEY
1–2 inset screen videos switch between VIDEO
IN 1–6
Ó
STILL 1–16 in order.
REVERSE
Each time you press a button, the PinP & KEY
1–2 inset screen videos switch between STILL
16–1
Ó
VIDEO IN 6–1 in order.
DSK SCAN
NORMAL
Each time you press a button, the DSK caption
video switches between VIDEO IN 1–6
Ó
STILL
1–16 in order.
REVERSE
Each time you press a button, the DSK caption
video switches between STILL 16–1
Ó
VIDEO IN
6–1 in order.
EXTERNAL REC CONTROL ––
Controls the recorder’s video record start/
stop if a recorder that supports REC control
functionality is connected.
MACRO EXECUTE MACRO 1–100
Executes a macro (a series of recorded
operations).
SEQUENCER –– Shows the sequencer execution screen.
STREAM/RECORD
SETUP Shows the streaming/recording setup screen.
START/STOP Starts/stops streaming or recording.
SAFETY IMAGE Turns the safety delay function on/o.
VIDEO PLAYER
SETUP Shows the video player setup screen.
START/PAUSE/STOP Starts/stops video playback.
GPO (ONE SHOT) GPO 1–16 Outputs a control signal for 0.5 seconds.
GPO (ALTERNATE) GPO 1–16
The control signal output is switched on/o
while the button is pressed.
CAMERA CONTROL ––
Turns the camera control function on/o. When
this is on, the VIDEO SWITCHER [1]–[6] buttons
can be used to recall the presets.
SYSTEM
EFFECTS TRANSITION
SYNC
Bluetooth CONTROL
Turns the Bluetooth function and EFFECTS
TRANSITION SYNC function on/o. Long-press
the button to begin pairing.
VIDEO OUT ASSIGN
VIDEO OUT ASSIGN A, B
N/A Hidden
CLOCK Shows the analog/digital clock.
STREAM/RECORD STATUS 1 Shows the streaming/video recording status.
STREAM/RECORD STATUS 2 Shows the streaming/video recording status.
