Menu List
Menu item
Value (bold text: default
value)
Explanation
EXTERNAL REC INDICATOR
Sets whether to display the REC indicator in the monitor.
When this is “ON”, a REC indicator showing that the camera’s REC button has been pressed is displayed, if the unit is
connected to a camera that supports the REC status function.
MULTI-VIEW OFF, ON Turns the REC indicator on/o for multi-view.
AUDIO LEVEL METER Species whether to display the audio level meter in the monitor.
MULTI-VIEW OFF, ON Turns the AUDIO LEVEL METER indicator on/o for multi-view.
MULTI-VIEW LAYOUT Species the videos to be shown in the PVW section (LEFT) and PGM section (RIGHT) in the multi-view.
LEFT
RIGHT
PROGRAM Final output video. This is the default setting for “RIGHT”.
SUB PROGRAM SUB PROGRAM bus video
PREVIEW Preview output video (the video to be output next). This is the default setting for “LEFT”.
AUX AUX bus video
BLACK Black screen
PREVIEW LABEL Species whether to display the label in the monitor.
MULTI-VIEW OFF, ON Turns the label on/o for multi-view.
STILL-VIEW OFF, ON Turns the label on/o for still-view.
LABEL EDIT
ENTER
Edit the label name shown in the monitor.
Press the [VALUE] knob to access the LABEL EDIT screen.
VIDEO IN 1–6, STILL 1–16, VIDEO PLAYER, PGM, SUB PGM, PVW, AUX
LABEL SIZE SMALL, NORMAL Species the text size of the label shown in the monitor.
LED DIMMER 1–8 Adjusts the brightness when the buttons or indicators are lit.
LCD DIMMER 1–8 Adjusts the brightness of this unit’s monitor.
AUTO INPUT DETECT OFF, ON
Turns the auto input detect function on/o.
When this is “ON”, input is automatically detected, and the video is switched when input from
the nal output video is interrupted.
AUTO FAN CONTROL OFF, ON
Turns the auto fan control function on/o.
When this is “ON”, this function controls the fan according to the internal temperature of this
unit.
TEST PATTERN Species the test pattern.
TEST PATTERN
OFF, COLOR BARS 75%,
COLOR BARS100%, RAMP,
STEP, HATCH, DIAMOND,
CIRCLE, COLOR BARS 75%-
SP,
COLOR BARS100%-SP,
RAMP-SP, STEP-SP, HATCH-
SP
Selects the test pattern to display.
MOTION DISABLE, SLOW, FAST Species the scroll speed of the test pattern.
TEST TONE Species the test tone.
TEST TONE OFF, -20, -10, 0dB Adjusts the test tone volume.
FREQUENCY L 500Hz, 1kHz, 2kHz Species the frequency of the test tone for the L-channel.
FREQUENCY R 500Hz, 1kHz, 2kHz Species the frequency of the test tone for the R-channel.
AUTO OFF (240min) OFF, ON
The power turns o automatically after a predetermined amount of time has passed since the
buttons or controls were operated.
SHUT DOWN EXEC Shuts down this unit.
FACTORY RESET EXEC Returns the unit to its factory defaults.
SYSTEM INFORMATION --- Displays the version of the system program.
