Menu List
GPI
Menu item
Value (bold text: default
value)
Explanation
GPI
These settings assign the functions to the GPI.
GPI 1–8
When an external control signal is input, the assigned functions are executed.
CATEGORY VALUE
Explanation
N/A –– No function is assigned.
PGM CH SELECT INPUT 1–6 Switches the video sent to the PGM bus.
PST CH SELECT INPUT 1–6 Switches the video sent to the PST bus.
AUX CH SELECT
VIDEO 1–6, STILL 1–16, V.PLAYER, INPUT 1–6 Switches the video sent to the AUX bus.
INPUT 1–6 ASSIGN VIDEO IN 1–6, STILL 1–16, V.PLAYER, N/A Changes the video assigned to INPUT 1–6.
STILL OUTPUT STILL 1–16
Pauses the normal output, and previews or nal outputs a cut
of the still image.
VIDEO PLAYER OUTPUT ––
Temporarily pauses the normal output, and previews or nal
outputs a cut of the video player’s video signal.
PinP & KEY 1–2 SOURCE
VIDEO 1–6, STILL 1–16, V.PLAYER, INPUT 1–6 Switches the video source of the inset screen.
DSK SOURCE
VIDEO 1–6, STILL 1–16, V.PLAYER, INPUT 1–6 Switches the DSK video source.
BUTTON CONTROL
CUT BUTTON, AUTO BUTTON
MIX BUTTON
WIPE BUTTON
SPLIT BUTTON
PinP & KEY 1–2 PVW BUTTON
PinP & KEY 1–2 PGM BUTTON
DSK PVW BUTTON
DSK PGM BUTTON
AUDIO EFFECT 1–3 BUTTON
AUDIO PLAYER 1–6 BUTTON
This works the same as when you press the button selected in
“VALUE”.
AUDIO INPUT MUTE
AUDIO IN 1–7/8, USB IN, Bluetooth IN,
AUDIO PLAYER, VIDEO 1–6, V.PLAYER
Turns the mute function on/o for the input audio.
AUDIO OUTPUT MUTE
MAIN BUS, AUX 1 BUS, AUX 2 BUS, USB
OUT, STREAM/RECORD
Turns the mute function on/o for the output audio.
AUDIO INPUT SOLO
AUDIO IN 1–7/8, USB IN, Bluetooth IN,
AUDIO PLAYER, VIDEO 1–6, V.PLAYER
Turns the solo function on/o for the input audio.
AUDIO OUTPUT SOLO MAIN BUS, AUX 1 BUS, AUX 2 BUS Turns the solo function on/o for the output audio.
VOICE CHANGER AUDIO IN 1, 2 Turns the voice changer function on/o.
AUTO MIXING –– Turns the auto switching function on/o.
REVERB(MOMENTARY) –– Reverb turns on only while a control signal is input.
REVERB(ALTERNATE) –– Turns reverb on/o.
OUTPUT FADE –– The nal output video fades in/out.
LOAD MEMORY MEMORY 1–32 Recalls a scene memory.
INPUT SCAN
NORMAL
Each time a control signal is input, the nal output switches
from INPUT 1–6 in sequential order.
REVERSE
Each time a control signal is input, the nal output switches in
reverse order from INPUT 6 through 1.
SCENE MEMORY SCAN
NORMAL
The scene memories 1 through 32 are recalled in order each
time a control signal is input.
REVERSE
The scene memories are recalled in reverse order from 32
through 1 each time a control signal is input.
PinP & KEY 1–2 SCAN
NORMAL
Each time you input a control signal, the PinP & KEY 1–2 inset
screen videos switch between VIDEO IN 1–6
Ó
STILL 1–16 in
order.
REVERSE
Each time you input a control signal, the PinP & KEY 1–2 inset
screen videos switch between STILL 16–1
Ó
VIDEO IN 6–1 in
order.
DSK SCAN
NORMAL
Each time you input a control signal, the DSK caption video
switches between VIDEO IN 1–6
Ó
STILL 1–16 in order.
REVERSE
Each time you input a control signal, the DSK caption videos
switch between STILL 16–1
Ó
VIDEO IN 6–1 in order.
MACRO EXECUTE MACRO 1–100 Executes a macro (a series of recorded operations).
SEQUENCER
MODE ON/OFF, NEXT, PREVIOUS,
AUTO SEQUENCE
When the sequencer function is on, this works the same as
when you press the button selected in “VALUE”.
GPO (ONE SHOT) GPO 1–16 Outputs a control signal for 0.5 seconds.
GPO (ALTERNATE) GPO 1–16
The control signal output is switched on/o each time a
control signal is input.
