134
Menu List
CTL/EXP
Menu item
Value (bold text:
default value)
Explanation
CTL/EXP 1, 2 These settings for the footswitch or expression pedal connected to the CTL/EXP 1, 2 jacks.
CTL/EXP TYPE
Settings for the devices (footswitch or expression pedal) connected to the CTL/EXP 1, 2 jacks.
OFF Disables the CTL/EXP jack.
CTL A & CTL B Choose this if a footswitch is connected.
EXP Choose this if an expression pedal is connected.
When CTL/EXP TYPE=CTL A & CTL B
ASSIGN Species the functions that are assigned to CTL A and CTL B of the footswitch.
CTL A
CTL B
CATEGORY VALUE
Explanation
N/A –– No function is assigned.
PGM CH SELECT INPUT 1–6 Switches the video sent to the PGM bus.
PST CH SELECT INPUT 1–6 Switches the video sent to the PST bus.
AUX CH SELECT INPUT 1–6 Switches the video sent to the AUX bus.
INPUT 1–6 ASSIGN
VIDEO 1–6, STILL 1–16, V.PLAYER, INPUT 1–6
Changes the video assigned to INPUT 1–6.
STILL OUTPUT STILL 1–16
Pauses the normal output, and previews or nal outputs a cut of the still image.
When a control signal is input again, the signal output returns to normal.
VIDEO PLAYER OUTPUT ––
Temporarily pauses the normal output, and previews or nal outputs a cut of the
video player’s video signal.
PinP & KEY 1–2 SOURCE
VIDEO 1–6, STILL 1–16, V.PLAYER, INPUT 1–6
Switches the video source of the inset screen.
DSK SOURCE
VIDEO 1–6, STILL 1–16, V.PLAYER, INPUT 1–6
Switches the DSK video source.
BUTTON CONTROL
CUT BUTTON, AUTO BUTTON
MIX BUTTON
WIPE BUTTON
SPLIT BUTTON
PinP & KEY 1–2 PVW BUTTON
PinP & KEY 1–2 PGM BUTTON
DSK PVW BUTTON
DSK PGM BUTTON
AUDIO EFFECT 1–3 BUTTON
AUDIO PLAYER 1–6 BUTTON
This works the same as when you press the button selected in “VALUE”.
AUDIO INPUT MUTE
AUDIO IN 1–7/8, USB IN, Bluetooth IN,
AUDIO PLAYER, VIDEO 1–6, V.PLAYER
Turns the mute function on/o for the input audio.
AUDIO OUTPUT MUTE
MAIN BUS, AUX 1 BUS, AUX 2 BUS, USB
OUT, STREAM/RECORD
Turns the mute function on/o for the output audio.
AUDIO INPUT SOLO
AUDIO IN 1–7/8, USB IN, Bluetooth IN,
AUDIO PLAYER, VIDEO 1–6, V.PLAYER
Turns the solo function on/o for the input audio.
AUDIO OUTPUT SOLO MAIN BUS, AUX 1 BUS, AUX 2 BUS Turns the solo function on/o for the output audio.
VOICE CHANGER AUDIO IN 1, 2 Turns the voice changer function on/o.
AUTO MIXING –– Turns the auto switching function on/o.
REVERB(MOMENTARY) –– Reverb turns on only while you press the footswitch.
REVERB(ALTERNATE) –– Turns reverb on/o.
OUTPUT FADE –– The nal output video fades in/out.
LOAD MEMORY MEMORY 1–32 Recalls a scene memory.
INPUT SCAN
NORMAL
Each time you press the footswitch, the nal output switches from INPUT 1–6 in
sequential order.
REVERSE
Each time you press the footswitch, the nal output switches in reverse order from
INPUT 6 through 1.
SCENE MEMORY SCAN
NORMAL
Each time you press the footswitch, scene memories 1–32 are recalled in
sequential order.
REVERSE
Each time you press the footswitch, scene memories are recalled in reverse order
from 32 through 1.
PinP & KEY 1–2 SCAN
NORMAL
Each time you press the footswitch, the PinP & KEY 1–2 inset screen videos switch
between VIDEO IN 1–6
Ó
STILL 1–16 in order.
REVERSE
Each time you press the footswitch, the PinP & KEY 1–2 inset screen videos switch
between STILL 16–1
Ó
VIDEO IN 6–1 in order .
DSK SCAN
NORMAL
Each time you press the footswitch, the DSK caption video switches between
VIDEO IN 1–6
Ó
STILL 1–16 in order.
REVERSE
Each time you press the footswitch, the DSK caption videos switch between STILL
16–1
Ó
VIDEO IN 6–1 in order.
MACRO EXECUTE MACRO 1–100 Executes a macro (a series of recorded operations).
SEQUENCER
MODE ON/OFF, NEXT, PREVIOUS,
AUTO SEQUENCE
When the sequencer function is on, this works the same as when you press the
button selected in “VALUE”.
GPO (ONE SHOT) GPO 1–16 Outputs a control signal for 0.5 seconds.
GPO (ALTERNATE) GPO 1–16 The control signal output is switched on/o with each press of the footswitch.
