Roland VR-6HD

135
Menu List
Menu item
Value (bold text:
default value)
Explanation
When CTL/EXP TYPE=EXP
ASSIGN Species the function that is assigned to the expression pedal.
EXP
CATEGORY VALUE
Explanation
N/A –– No function is assigned.
VIDEO FADER FADE, CUT
FADE:
Operates the video fader.
CUT:
Cuts between the nal output video and the preview video.
STILL OUTPUT STILL 1–16
Pauses the normal output, and previews or nal outputs a cut of the still
image.
VIDEO PLAYER
OUTPUT
––
Temporarily pauses the normal output, and previews or nal outputs a
cut of the video player’s video signal.
AUDIO INPUT LEVEL
AUDIO IN 1–7/8, USB IN,
Bluetooth IN,
AUDIO PLAYER
VIDEO 1–6, V.PLAYER
Adjusts the input volume.
AUDIO OUTPUT
LEVEL
MAIN BUS, AUX 1 BUS, AUX 2 BUS,
USB OUT, STREAM/RECORD
Adjusts the output volume.
VOICE CHANGER
AUDIO IN 1 PITCH
AUDIO IN 1 FORMANT
AUDIO IN 1 MIX
AUDIO IN 2 PITCH
AUDIO IN 2 FORMANT
AUDIO IN 2 MIX
Adjusts the balance between the unprocessed voice (0) and the voice
processed by the eect (100).
REVERB LEVEL ––
Adjusts the amount of sound that is returned from the reverb (return
level).
CALIBRATION ENTER
The EXP CALIBRATION screen appears.
Following the direction on the screen, calibrate (adjust) the expression pedal.
The rst time you use the expression pedal, be sure to execute calibration so that the pedal will operate
optimally.
In some cases, the expression pedal might no longer be operating optimally because of the passage of time
or the conditions of use. In such cases you should also execute expression pedal calibration.
Bluetooth
Menu item Value (bold text: default value) Explanation
Bluetooth PAIRING These are the Bluetooth-related settings.
Bluetooth OFF, ON Turns the Bluetooth function on/o.
PAIRING
EXEC Begins pairing with a Bluetooth device.
STATUS
Displays the Bluetooth connection status.
OFF Bluetooth o
PAIRING MODE Now pairing
NOT CONNECTED Waiting for connection
CONNECTED Connected
CAMERA CONTROL
Menu item Value (bold text: default value) Explanation
CAMERA ID CAMERA 1–6 Selects the camera to be controlled.
PROTOCOL
N/A, JVC, Panasonic, Canon PTZ,
VISCA over IP, PTZOptics, Avonic
Species the camera’s protocol.
IP ADDRESS 192.168.0.101 Input the camera’s IP address.
LOGIN NAME ENTER
Displays the LOGIN NAME screen.
Enter the login name needed to connect with the camera when “PROTOCOL” is “JVC”.
PASSWORD ENTER
Displays the PASSWORD screen.
Enter the password needed to connect with the camera when “PROTOCOL” is “JVC”.
CAMERA PRESET PRESET 1–6 Selects the preset used when recalling or registering the settings.
RECALL EXEC Touch the screen to recall the preset from a camera.
ALL CAMERAS RECALL
OFF Recall presets from the camera that is being controlled.
ON Simultaneously recall presets from all cameras (CAMERA 1–6).
STORE EXEC
Touch the screen to register the settings from a camera as a preset.
* Presets are saved in the camera itself.
TALLY CH VIDEO IN 1–6
Species the connector from which the camera video is input. When the camera video from
the VR-6HD is the nal output, the camera’s tally light is lit.
