Roland VR-6HD

113
Menu List
Menu item Value (bold text: default value) Explanation
EQUALIZER OFF, ON
Turns the equalizer on/o.
Eect
This is a 4-band parametric equalizer. It lets you shape the character of the sound by
boosting or cutting four frequency regions.
Hi GAIN -12.0–0.0–12.0dB Boosts or attenuates the high band.
Hi FREQUENCY 1.00–10.0–20.0kHz Adjusts the center frequency when changing the tone quality in the high band.
Hi-Mid GAIN -12.0–0.0–12.0dB Boosts or attenuates the high-midrange band.
Hi-Mid FREQUENCY 20Hz–2.00kHz–20.0kHz
Adjusts the center frequency when changing the tone quality in the high-midrange
band.
Hi-Mid Q 0.5–1.0–16.0
Adjusts the width of the frequency band when boosting or attenuating high-midrange
band.
Lo-Mid GAIN -12.0–0.0–12.0dB Boosts or attenuates the low-midrange band.
Lo-Mid FREQUENCY 20Hz–500Hz–20.0kHz Adjusts the center frequency when changing the tone quality in the low-midrange band.
Lo-Mid Q 0.5–1.0–16.0
Adjusts the width of the frequency band when boosting or attenuating low-midrange
band.
Lo GAIN -12.0–0.0–12.0dB Boosts or attenuates the low band.
Lo FREQUENCY 20Hz–100Hz–2.00kHz Adjusts the center frequency when changing the tone quality in the low band.
AUDIO OUTPUT ASSIGN
Menu item Value (bold text: default value) Explanation
AUDIO OUT 1 (XLR)
MAIN BUS, AUX 1 BUS, AUX 2 BUS,
MONITOR BUS
MAIN BUS:
All input audio is mixed and output (master output).
AUX 1 BUS, AUX 2 BUS:
Only the input audio sent to the AUX bus is mixed and output. This allows you to output
audio that is dierent than the master output.
MONITOR BUS:
This outputs the same audio as what you hear in the headphones.
AUDIO OUT 2 (RCA)
MAIN BUS, AUX 1 BUS, AUX 2 BUS,
MONITOR BUS
PHONES OUT/
MONITOR
MAIN BUS, AUX 1, AUX 2
USB OUT
MAIN BUS, AUX 1, AUX 2
STREAM/RECORD
MAIN BUS, AUX 1, AUX 2
AUDIO RECORD
MAIN BUS, AUX 1, AUX 2
VIDEO OUT 1–3
MAIN BUS, AUX 1 BUS, AUX 2 BUS,
MONITOR BUS
