Roland VR-6HD

120
Menu List
Menu item
Value (bold text: default
value)
Explanation
USB OUT Adjusts the audio that’s output from the USB STREAM connector.
LEVEL
-INF–0.0–10.0dB
Adjusts the output volume.
This can also be adjusted by the [USB STREAM] knob.
MUTE
OFF, ON Turns the mute function on/o. When this is “ON”, the output audio is temporarily silenced.
DELAY
0.0–500msec
(0–25.0/29.9/30.0frame)
Adjusts the delay time of the audio.
Eect Outputs audio with a delay.
EQUALIZER OFF, ON
Turns the equalizer on/o.
Eect
This is a 4-band parametric equalizer. It lets you shape the character of the sound by
boosting or cutting four frequency regions.
Hi GAIN -12.0–0.0–12.0dB Boosts or attenuates the high band.
Hi FREQUENCY 1.00–10.0–20.0kHz Adjusts the center frequency when changing the tone quality in the high band.
Hi-Mid GAIN -12.0–0.0–12.0dB Boosts or attenuates the high-midrange band.
Hi-Mid FREQUENCY 20Hz–2.00kHz–20.0kHz Adjusts the center frequency when changing the tone quality in the high-midrange band.
Hi-Mid Q 0.5–1.0–16.0
Adjusts the width of the frequency band when boosting or attenuating high-midrange
band.
Lo-Mid GAIN -12.0–0.0–12.0dB Boosts or attenuates the low-midrange band.
Lo-Mid FREQUENCY 20Hz–500Hz–20.0kHz Adjusts the center frequency when changing the tone quality in the low-midrange band.
Lo-Mid Q 0.5–1.0–16.0 Adjusts the width of the frequency band when boosting or attenuating low-midrange band.
Lo GAIN -12.0–0.0–12.0dB Boosts or attenuates the low band.
Lo FREQUENCY 20Hz–100Hz–2.00kHz Adjusts the center frequency when changing the tone quality in the low band.
STREAM/RECORD Adjusts the audio that’s output from the DIRECT STREAM port.
LEVEL
-INF–0.0–10.0dB
Adjusts the output volume.
This can also be adjusted by the [STREAM/RECORD] knob.
MUTE
OFF, ON Turns the mute function on/o. When this is “ON”, the input audio is temporarily silenced.
DELAY
0.0–500msec
(0–25.0/29.9/30.0frame)
Adjusts the delay time of the audio.
Eect Outputs audio with a delay.
EQUALIZER OFF, ON
Turns the equalizer on/o.
Eect
This is a 4-band parametric equalizer. It lets you shape the character of the sound by
boosting or cutting four frequency regions.
Hi GAIN -12.0–0.0–12.0dB Boosts or attenuates the high band.
Hi FREQUENCY 1.00–10.0–20.0kHz Adjusts the center frequency when changing the tone quality in the high band.
Hi-Mid GAIN -12.0–0.0–12.0dB Boosts or attenuates the high-midrange band.
Hi-Mid FREQUENCY 20Hz–2.00kHz–20.0kHz Adjusts the center frequency when changing the tone quality in the high-midrange band.
Hi-Mid Q 0.5–1.0–16.0
Adjusts the width of the frequency band when boosting or attenuating high-midrange
band.
Lo-Mid GAIN -12.0–0.0–12.0dB Boosts or attenuates the low-midrange band.
Lo-Mid FREQUENCY 20Hz–500Hz–20.0kHz Adjusts the center frequency when changing the tone quality in the low-midrange band.
Lo-Mid Q 0.5–1.0–16.0 Adjusts the width of the frequency band when boosting or attenuating low-midrange band.
Lo GAIN -12.0–0.0–12.0dB Boosts or attenuates the low band.
Lo FREQUENCY 20Hz–100Hz–2.00kHz Adjusts the center frequency when changing the tone quality in the low band.
MONITOR/PHONES OUT Adjusts the audio that is output from the PHONES jack.
MONITOR LEVEL
-INF–10.0dB Adjust the monitor volume.
PHONES LEVEL
-INF–10.0dB Adjusts the output volume. This can also be adjusted by the [PHONES] knob.
FADER ASSIGN
Menu item Value (bold text: default value) Explanation
INPUT FADER 1–7/8
AUDIO IN 1–7/8, USB IN, Bluetooth IN,
AUDIO PLAYER, VIDEO 1–6, V. PLAYER
The default values are as follows.
INPUT FADER 1: AUDIO IN 1
INPUT FADER 2: AUDIO IN 2
INPUT FADER 3: AUDIO IN 3
INPUT FADER 4: AUDIO IN 4
INPUT FADER 5: AUDIO IN 5
INPUT FADER 6: AUDIO IN 6
INPUT FADER 7/8: AUDIO IN 7/8
Selects the audio input to assign to each fader.
