Ruijie RG-WLAN Series User Manual

Configuration Guide Configuring VLAN Group
The STA will be authenticated in the default VLAN. After authentication succeeds, the authentication server determines
whether to assign a VLAN. If yes, the packets subsequently sent by the STA will be automatically redirected to the assigned
VLAN. If no, the packets will be transmitted in the default VLAN of the VLAN group.
4.4 Configuration
Configuration
Description and Command
Configuring a VLAN Group
(Mandatory) It is used to create a VLAN group and configure a VLAN list, the VLAN
assignment mode, and default VLAN.
vlan-group group-id
Creates a VLAN group.
vlan-list vlan-list
Configures a VLAN list for a VLAN group.
vlan-assign-mode XX
Specifies the VLAN assignment mode for a
VLAN group.
default-vlan XX
Configures the default VLAN for a VLAN
group.
Configuring WLAN-VLAN
Group Mapping
(Mandatory) It is used to configure the mapping between a WLAN and a VLAN group.
dot11 wlan wlan-id
vlan-group group-id
Configures WLAN-VLAN group mapping on
APs.
4.4.1 Configuring a VLAN Group
Configuration Effect
 Create a VLAN group and complete configurations related to the VLAN group.
Notes
 N/A
Configuration Steps
 Creating a VLAN Group
 Mandatory.
Command
vlan-group group-id
Parameter
Description
group-id: indicates the ID of a VLAN group, ranging from 1 to 128.
Defaults
No VLAN group is created.
Command
Mode
Global configuration mode
Usage Guide
N/A
