Sakura Tissue-Tek Prisma Plus User Manual

1-19
Specification "DRS-Prisma-P-JD/JS"
"DRS-Prisma-P-JCS"
General name
Automated slide stainer
Brand name
Tissue-Tek Prisma®Plus
Model
Prisma-P-JD
Prisma-P-JS
Prisma-P-JCS
Product code
6174
6175
6177
Manufacturing license number
20B2X00014000034
Dimensions
1250 (W) x 713 (D) x 650 (H) mm (excluding the control monitor)
Weight
Approximately 150 kg
Rated power supply
Single-phase 100 VAC ± 10%, 50/60 Hz, 10 Amps
Single-phase 230 VAC ± 10%, 50/60 Hz, 5.5 Amps
Power consumption
1000 VA
Electric shock protection
Class I, overvoltage category II
Pollution degree
Pollution degree I
Capabilities
Stain process
Batch mode: 60, 20 or 10 slides Continuous mode: Up to 11 runs can be set
in the instrument .
Staining programs
Up to 50 programs can be stored. One program can consist of up to 50
steps.
Standard solution name
Up to 100 solution names can be stored.
Solution configuration name
Up to 50 solution configurations can be stored.
Drying station
Temperature setting range: 30 to 65C
Heating station
-
Temperature setting range: 30 to 70C
Required
facilities
Power supply
Voltage = Rated voltage  10%, 50/60 Hz
Current capacity = Rated current min.
Grounding = Comes with grounding bar conforming to class D grounding
Water supply
Water = Tap water
Pressure
Dynamic water = 0.098 to 0.441 MPa
Maximum static pressure = 0.74 MPa
Temperature = 30C max. (non-freezing)
Nominal pipe diameter = 15A (1/2 in) min.
Drain
Method = Indirect draining
Drain capacity = 15 L per minute min.
Nominal pipe diameter = 40A (1-1/2 in) min.
Operating
environment
Ambient temperature
10 to 40C
Relative humidity
30 to 85% (non-condensing)
Storage
environment
Ambient temperature
-10 to 65C (instrument interior must be drained.)
Relative humidity
20 to 90% (non-condensing)
Vibration/drop
Drop testJISZ0200:2013 (Level 1)
Vibration test JIS Z0232: 2004 (Standard of Truck Transportation)
Noise
65 dB or less (A characteristics)
Law and
conforming
standard
Applicable instruments
DRS-Prisma-P-JD/JS
DRS-Prisma-P-JCS
Law
Law Regarding Ensuring of
Quality, Effectiveness and
Safety of Drugs, Medical
Equipment, Etc., and Other
Pharmaceutical and Medical Device Act
(Manufacturing and Sales Notification, Export
Notification), CFDA, Ordinance on
Supervision and Control of Medical Devices,
Class 1 Equipment, Administrative Regulation
Pertaining to Limitations of Use of Harmful
Substances in Electrical and Electronic
Products
Electrical safety evaluation
Law Regarding Ensuring of
Quality, Effectiveness and
Safety of Drugs, Medical
Equipment, Etc., and Other
CFDA, Ordinance on Supervision and Control
of Medical Devices, Class 1 Equipment
GB 4793.1-2007 (IEC 61010-1: 2010)
JISC 1010-1: 2014
GB 4793.6-2006 (IEC 61010-2-010: 2003)
JISC 1010-2-101: 2013
YY 0648-2008 (IEC 61010-2-101: 2002)
Risk management
JIST 14971: 2012
Medical equipment software
JIST 2304: 2012
Quality management
ISO 13485: 2005
Electromagnetic
compatibility
JISC 1806-2-6: 2012
GB/T 18268.1-2010 (IEC 61326-1: 2005)
GB/T 18268.26-2010 (IEC 61326-2-6: 2005)

Sakura Tissue-Tek Prisma Plus Specifications

General

Brand	Sakura
Model	Tissue-Tek Prisma Plus
Category	Laboratory Equipment
Language	English
