Sakura Tissue-Tek Prisma Plus User Manual

Specification "Prisma-P-ED/ES"
1-18
General name
Automated slide stainer
Brand name
Tissue-Tek Prisma®Plus
Model
Prisma-P-ED
Prisma-P-ES
Product code
6172
6173
Manufacturing license number
20B2X00014000034
Dimensions
1250 (W) x 713 (D) x 650 (H) mm (excluding the control monitor)
Weight
Approximately 150 kg
Rated power supply
Single-phase 230 VAC ± 10%, 50/60 Hz, 5.5 Amps
Power consumption
1000 VA
Electric shock protection
Class I, overvoltage category II
Pollution degree
Pollution degree I
Capabilities
Stain process
Batch mode: 60, 20 or 10 slides
Continuous mode: Up to 11 runs can be set in the instrument.
Staining programs
Up to 50 programs can be stored.
One program can consist of up to 50 steps.
Standard solution name
Up to 100 solution names can be stored.
Solution configuration name
Up to 50 solution configurations can be stored.
Drying station
Temperature setting range: 30 to 65C
Heating station
-
Temperature setting range: 30 to 70C
Required
facilities
Power supply
Voltage = Rated voltage  10%, 50/60 Hz
Current capacity = Rated current min.
Grounding = Comes with grounding bar conforming to class D
grounding
Water supply
Water = Tap water
Pressure
Dynamic water = 0.098 to 0.441 MPa
Maximum static pressure = 0.74 MPa
Temperature = 30C max. (non-freezing)
Nominal pipe diameter = 15A (1/2 in) min.
Drain
Method = Indirect draining
Drain capacity = 15 L per minute min.
Nominal pipe diameter = 40A (1-1/2 in) min.
Operating
environment
Ambient temperature
10 to 40C
Relative humidity
30 to 85% (non-condensing)
Storage
environment
Ambient temperature
-10 to 65C (instrument interior must be drained.)
Relative humidity
20 to 90% (non-condensing)
Vibration/drop
Drop test JISZ0200:2013 (Level 1)
Vibration test JISZ0232: 2004 (Standard of Truck Transportation)
Noise
65 dB or less (A characteristics)
Law and
conforming
standard
Law
CE Marking
IVD Directive (98/79/EC)
RoHS Directive (2011/65/EU)
Electrical safety evaluation
CE Marking & IVD Directive
EN 61010-1: 2010
EN 61010-2-010: 2003
EN 61010-2-101: 2002
Risk management
EN 14971: 2012
EN 62366: 2008
Medical equipment software
EN 62304: 2006
Quality management
ISO 13485: 2004
Electromagnetic compatibility
EN 61326-2-6: 2006
