Switching the Power-supply Voltage Setting
This instrument supports multiple voltages, but the setting on the instrument side must be switched
according to the power-supply voltage. If the instrument is used without switching the voltage
setting, not only the instrument will break down, but the user may also be exposed to danger;
accordingly, contact the Sakura Finetek Technical Support representative or local representative
when the instrument is installed to switch the voltage setting according to the voltage on the facility
side. The factory setting is 230 V.
Product models in the instruction sheet are as shown below. Pay attention that accessories are different
depending on the model.
Tissue-Tek PrismaPlus (Model Prisma-P-AD)
Tissue-Tek PrismaPlus (Model Prisma-P-AS)
w/ Drying/Heating/Special Staining Functions
Tissue-Tek PrismaPlus (Model Prisma-P-ED)
Tissue-Tek PrismaPlus (Model Prisma-P-ES)
w/ Drying/Heating/Special Staining Functions
Tissue-Tek PrismaPlus (Model DRS-Prisma-P-JD)
Tissue-Tek PrismaPlus (Model DRS-Prisma-P-JS)
w/ Drying/Heating/Special Staining Functions
Tissue-Tek PrismaPlus (Model DRS-Prisma-P-JCS)
w/ Drying/Heating/Special Staining Functions
Confirm that all accessories (refer to the table below) are present and that the instrument and
accessories are free from damage, and if the instrument is damaged or any of the accessories is short
or damaged, contact the Sakura Finetek sales representative.
3-position reservoir tray (2-phase stainless) *3
3-position reservoir tray
4-position reservoir tray (2-phase stainless) *3
4-position reservoir tray
Control panel protection sheet
Comes attached to the control panel
Hot air outlet panel, drying station
Heating solution reservoir
Water supply hose (faucet connection type)
Drain hose unit (38 mm × 2 mm + cuffs)
Power cord 100/115 VAC power plug
Power cord 230 VAC power plug
For input in case of power outage
Of the four pieces, two are preinstalled on the instrument.
Of the four pieces, two are preinstalled on the instrument.
Cap for covering water supply port
Of the four pieces, two are preinstalled on the instrument.
For LAN port; installed on the port.
For RS232C port; installed on the port.
Station labels (Start, End)
Package insert for medical equipment
Excerpt from Unpacking/Installation Manual
Warranty registration card
10-slide basket load adapter
Special stain solution reservoir
Lid, special stain solution reservoir
Special stain reservoir tray (2-phase stainless)
Special stain reservoir tray
Standard solution reservoir
Solution reservoir with handle
Lid, standard solution reservoir
Large lid, 3-position reservoir tray (2-phase stainless)
Large lid, 3-position reservoir tray
Large lid, 4-position reservoir tray (2-phase stainless)
Large lid, 4-position reservoir tray
Standard solution reservoir set (sold as a set) *2
Standard solution reservoir
Solution reservoir with handle
Lid, standard solution reservoir
Small solution reservoir set (sold as a set) *2
Solution reservoir with handle
Lid, standard solution reservoir
Lid, small solution reservoir
20-slide basket load/unload adapter
