6
When data are Output without decimals, the decimal point is suppressed (except when a certain display mode is selected).
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
+ * * * * *
* * 10
7
10
6
10
5
10
4
10
3
10
2
10
1
10
0
*
* * *
0 0 0 0 0 0 0 0
–
· · · · · · · ·
E E E
CR LF
Data output example: +150.11775 g
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
+ 1 5 0 · 1 1 7 7 5 * g * * CR LF
Characters:
1
st
Plus or minus sign or space
2
nd
– 10
th
Weight with a decimal point; leading zeros = space
11
th
Space
12
th
– 14
th
Unit symbol or space
15
th
Carriage Return (CR)
16
th
Line Feed (LF)
— lf the weighing System has not stabilized, no unit symbol is Output.
— For the display formal parameter "last numeral off or only at stability" (blank last numeral by a rounding factor of 10 or
display last numeral when the readout is stable), the 10th character in the string is a space. The reason: the last numeral
without a decimal point is not blanked. Instead, it is given a definite zero, otherwise the display would go completely
blank when the balance is unloaded. In this case. you will obtain the Standard display formal.
Unit symbol (standard balance):
* * *
No stability parameter
t l s
Singapore taels
g * *
Grams
t l t
Taiwanese taels
k g *
Kilograms
g r *
Grains
c t *
Carats
d w t
Pennyweights
l b *
Pounds
m g *
Milligrams
o z *
Ounces
% * *
Percent
o z t
Troy ounces
p c s
Pieces (parts)
t l h
Hong Kong taels
