10
Sieve Analysis Code 2 1 5
Additional menu codes used in the example:
Function Code
With data lD code 7 2 2
As an alternative, you can select
this Output parameter:
Ref. % + ref. weight 7 1 2 Reference weight 7 1 3
Tare memory 2 2 2
Output individual tare wt. * 7 3 1
Application: sieve analysis of granular substances
Step/(key lD)/key Readout Dataoutput/printout
Place Container for sample
on the pan
+ 11.18522 g
,
0.00000 g
Add sample to Container + 85.06692 g
Store weight as 100%:
(STO REF)
+ 100.0 %
pRef
Wxx%
+ 100 %
+ 85.06692 g
Add sample to top sieve
on the Stack; shake
xx.x %
Place empty Container
on the pan and press
0.0 %
Pour contents of sieve 1
into Container:
TAR
+ 12.6 %
+ 0.0 %
Net
Prc
N1
+ 12.6 %
+ 10.70591 g
Add contents of
sieve 2:
TAR
+ 34.8 %
+ 0.0 %
Net
Prc1
N1
+ 34.8 %
+ 29.62297 g
Add & store contents
of remaining sieves
The data ID codes mean
pRef
Wxx%
Prc
N
+
+
-
-
100 %
85.06692 g
12.6 %
10.70591 g
reference percentage
net reference weight xx%
percentage of the sample
net weight of a component
* = Factory setting
