PR 5220 Instrument Manual Global SPM Variables
Sartorius EN-147
Format Address for
read [R]/
write [W]
Funktion Address
DINT R MAX weight (FSD) D14
DINT R MIN weight D15
DINT W Counter will be incremented on every PLC-cycle D23
DINT W Weight limit 1 on D24
DINT W Weight limit 1 off D25
DINT W Weight limit 2 on D26
DINT W Weight limit 2 off D27
DINT W Weight limit 3 on D28
DINT W Weight limit 3 off D29
UDINT W Analog output for 'transparent' mode D30
DINT W Write the value in the fixtare memory D31
REAL R Current gross value (as float) R264
REAL R Current net value (as float) R265
REAL R Current tare value (as float) R266
REAL R Gross/net selected by X72 (as float) R267
REAL R Max value from scale (FSD) (as float) R270
REAL R Min value from scale (as float) R271
REAL R/W Limit 1 on value (as float) R280
REAL R/W Limit 1 off value (as float) R281
REAL R/W Limit 2 on value (as float) R282
REAL R/W Limit 2 off value (as float) R283
REAL R/W Limit 3 on value (as float) R284
REAL R/W Limit 3 off value (as float) R285
REAL R/W Preset for fix tare (as float) R287
INT R Conversion counter W14
For communication via OPC the system variables (e. g.: ST_WGT_A) are described in the
operating manual PR 1792 (Chapter 4 + 5).
