Sartorius PR 5220 Series User Manual

Commissioning PR 5220 Instrument Manual
EN-80 Sartorius
In this example, a weight of 5000 g is put onto the scale.
The following window is displayed after applying the weight:
Weighingpoint/xBPI-Scale Setup
Calibration status
Difference display
Cal-Delta
0.1 g
--
5000.06 g
The weight is displayed in high-resolution (10x).
Select [Accept].
Accept
ResError
Abort
The data are saved and the instrument generates a corresponding message:
Weighingpoint/xBPI-Scale Setup
Calibration status
complete
Net=Grs
5000.0 g
--
5000.01 g
The weight is displayed in high-resolution (10x).
Leave with .
Accept
ResError
Abort
4.5.9 xBPI Calibration with Default Weight
Prerequisites:
- The xBPI protocol has been selected (see Chapter 4.5.1).
- The weighing point ‚xBPI-scale’ has been selected (see Chapter 4.5.4).
- The platform configuration has been executed (see Chapter 4.5.3).
- The setting in the following menu has been done: [Weighingpoint A-xBPI-Scale]-[Setup]:
[Configuration]-[Confirming adjust.]: [manual] (see Chapter 4.5.5).
- The communication between instrument and platform is active.
Weighingpoint/xBPI-Scale Setup
Calibration
Open with .
Configuration
Select group of specification
Show device info
Weighingpoint/xBPI-Scale Setup
Adjust with default weight
Select with and enter with .
Adjust with intern weight
Linearity
Default
User
