PR 5220 Instrument Manual Global SPM Variables

Sartorius EN-145

8 Global SPM Variables

Definined ranges are assigned to firmware functions.

Weights are DINT formats in 'kg' or 'lb', depending on scale configuration.

For communication via OPC, the following variables are available:

Format Address for

read [R]/

write [W]

Funktion Address

BOOL R Digital input 1 X0

BOOL R Digital input 2 X1

BOOL R Digital input 3 X2

BOOL R Digital output 1 X8

BOOL R Digital output 2 X9

BOOL R Digital output 3 X10

BOOL R Output limit 1 X16

BOOL R Output limit 2 X17

BOOL R Output limit 3 X18

BOOL R ADC error X32

BOOL R Above Max (FSD) X33

BOOL R Overload, above (Max + plus the range that is still permissible) X34

BOOL R Below zero X35

BOOL R Zero ±¼d X36

BOOL R Within the zero setting range X37

BOOL R The weight is stable X38

BOOL R Below zero or above Max X39

BOOL R Load cell measuring signal negative (error 7) X40

BOOL R Load cell measuring signal >36 mV (error 3) X41

BOOL R Internal arithmetic error; CAL data are perhaps faulty (error 1) X42

BOOL R No or too low sense voltage (error 6) X43

BOOL R No Communication with xBPI scale (error 9) X44

BOOL R Command error X48

BOOL R Command active X49

BOOL R Power fail signal X50

BOOL R Test mode active X56

BOOL R Calibration active X57

BOOL R Instrument is tared X58

BOOL R/W Read/write marker bit 1 X64

BOOL R/W Read/write marker bit 2 X65

BOOL R/W Read/write marker bit 3 X66

BOOL W Switch D11 to net weight X72
