PR 5220 Instrument Manual Commissioning
Sartorius EN-79
The data are saved and the instrument generates a corresponding message:
Weighingpoint/xBPI-Scale Setup
Calibration status
complete
Net=Grs
2000 g
--
2000.01 g
The weight is displayed in high-resolution (10x).
Leave with .
Accept
ResError
Abort
4.5.8 xBPI Calibration with Automatic Weight Detection
Prerequisites:
- The xBPI protocol has been selected (see Chapter 4.5.1).
- The weighing point ‚xBPI-scale’ has been selected (see Chapter 4.5.4).
- The platform configuration has been executed (see Chapter 4.5.3).
- The setting in the following menu has been done: [Weighingpoint A-xBPI-Scale]-[Setup]:
[Configuration]-[Confirming adjust.]: [manual] (see Chapter 4.5.5).
- The communication between instrument and platform is active.
Weighingpoint/xBPI-Scale Setup
Calibration
Open with .
Configuration
Select group of specification
Show device info
Weighingpoint/xBPI-Scale Setup
Dead load
Set
Delete
Span
Adjust with user weight
Adjust with auto weight
Select with and enter with .
Following window appears:
Weighingpoint/xBPI-Scale Setup
Calibration status
Load to small
Calibration progress without weight.
Cal-Target
-10000.0 g
The weight is displayed in high-resolution (10x).
--
-0.02 g
