Commissioning
PR 5220 Instrument Manual
EN-66 Sartorius
4.4.11 Test Value Determination/Display
Press [Test] to activate test value calculation. The maximum capacity (Max) is displayed with the
designation
without a weight unit.
The value determined during calibration after starting the test [CalcTest] is shown.
Weighingpoint/WP A/Calibration
Depending on the settings under -[Weighingpoint]-[Calib]-[Param]-[Test mode], either
- the maximum capacity with [Absolute], or
- the deviation from the test value with [Relative]
is shown when you press
to view the test data.
4.4.12 Finishing/Saving the Calibration
Finish the calibration with .
You are prompted to confirm whether calibration should be closed without
determining the test value.
If not all data was determined when calibrating with [New] (e.g. dead load
not set/entered), this message is shown:
Press [Yes] to confirm and then press again; another prompt is displayed:
Press [Save] to save changes in calibration data. If you press [Undo], changes
are not saved and the display returns to the selection menu for the
weighing points.
The confirmation is displayed as follows:
Saving calibration
After quitting the menu, the following message is displayed:
Exit calibration
After finishing the calibration, set the CAL switch to the closed position; see also Chapter 4.1.1.
