4.4.8 Calibration with Load Cell Data (“Smart Calibration“)
If the scale to be calibrated is not legal for trade, it can be calibrated without weights. The easiest method is
the one using load cell data without calculation [by data].
Weighingpoint/WP A/Calibration
Max
3000 d
3000 kg
Scale interval
3000 d
1 kg
Deadload at
3.00 kg
0.001000
Max at
3000.00 kg
0.000000
Not calibrated
Sensitivity
833.33
4.000000
by load
by mV/V
by data
Linear.
CalcTest
Start by pressing [by data].
Weighingpoint/WP A/Calibration/Load cell configuration
Number of load cells
4
Nominal load
3000 kg
Gravity
9.81379 m/s²
Hysteresis error
not specified
Certified data
all LC same
LC sensitivity
1.000000
Enter
Calc
Weighingpoint/WP A/Calibration/Load cell configuration
LC resistance
600.000
¥
Enter
Calc
[Number of load cells]
Number of load cells connected in parallel (1, 2...<4>...9, 10)
[Nominal load]
Max. capacity E
max
of a load cell (not the overall nominal weight of the scale).
[Gravity]
Acceleration of gravity at the place of installation; default is the value for Hamburg, Germany, 9.81379 m/s².
[Hysteresis error]
When switching from [Not specified] to [Specified], values for [Correction A/B] must be filled in. The data is
given on the load cell certificate.
[Certified data], [LC sensitivity], [LC resistance]
With [all LC same], only 1 value for the sensitivity [LC sensitivity] and the output resistance [LC resistance]
must be filled in. With [each LC specific], individual values for each load cell are requested.
[Calc]
The mV/V value is calculated and after confirmation with [OK], the calculated mV/V value is stored in the
calibration data.
