4.3.6 INFO Function
When you press , the program releases and status messages are displayed. The key also has other
functions; see Chapters 4.4.1.1 and 4.4.9.
Info
Show version
Show status
Show HW-slots
When you select [Show version], the installed program releases and the board number are displayed:
Info/Version
Firmware
Rel. 02.00.00.00000
Firmware release and creation date
2010-11-11 11:11
PR5220-Application Rel. 01.20.06
Application release and creation date
2010-11-11 11:11
Bios
Rel 02.00.00.00000
BIOS release and creation date
2010-11-11 11:11
Boardnumber 275401089
Main board identification number
(different from the device serial number)
When you select [Show status], instrument status information is displayed:
Info/Status
Free system RAM
6328 of 15212 kb
Cal-Switch
closed
(‘opened’ if CAL switch is open)
When you select [Show HW-slots], the installed plug-in cards are displayed:
Info/HW-Slots
Builtin RS 485
Standard serial interface
Builtin analog out
Standard interface, analog outputs
Builtin digital i/o
Standard interface, digital I/Os
4.3.7 Setup Function (VNC)
Press to configure the main operating parameters. The instrument configuration depends on the
application and the plug-in cards installed.
Calibration is in a simple dialogue. Compliance with the relevant (verification) standards must be checked by
the person commissioning the instrument or the verification officer. To protect the calibration data from
overwriting, close the CAL switch on the back panel of the instrument. On legal-for trade instruments, the
CAL switch must be sealed in the closed (write-protected) position; see Chapter 4.1.1.
