Specifications
PR 5220 Instrument Manual
EN-162 Sartorius
14.5 Mechanical Data
14.5.1 Construction
Polyamide housing for mounting rail, black, flammability class V0 (UL94).
14.5.2 Dimensions
Housing: PR 5220/00 PR 5220/01, -/04, -/06, -/07
Width 45 mm 68 mm
Height 99 mm 99 mm
Depth 116 mm 116 mm
14.5.3 Weight
Net weight PR 5220/00 PR 5220/01, -/04, -/06, -/07
0.29 kg 0.35 kg
14.6 Use in Legal-for-Trade Mode
The Guide to Verification and further documents can be found on the Internet at
www.sartorius-mechatronics.com
14.6.1 Documentation for Verification on the Enclosed CD
The enclosed CD has a directory containing the following PDF documents (in preparation):
- EC Declaration of Conformity to Council Directive 90/384/EEC
- Plates and markings (sealing and labels)
- Test certificate for the instrument
- EC type approval
14.6.2 Additional Instructions
Information on the meaning of the CAL switch to be sealed can be found in Chapter 4.1.1 .
Make sure when configuring the instrument (see Chapter 4.4.13 ) that the settings are in compliance with the
legal requirements as well as with the requirements of the EC Type Approval and the EC Test Certificate.
Furthermore, the settings and functions described under Item 7 of the EC Test Certificate (Orders and
Conditions) must be checked. The person performing installation is responsible for selecting the legally
permitted settings. The settings must be checked.
