9 Configuration Print-Out
The configuration data can be saved as follows:
• Click [File]-[Save as…].
• Select the corresponding directory in window [Save website], fill in the required file name and select the
‘txt’ file type.
• Click [Save].
Configuration of PR5220
=======================================
Firmware : Rel 02.00.00.00000
2010-11-11 11:11
PR5220-Application : Rel 02.00.00
2010-11-11 11:11
Bios : Rel 02.00.00.00000
2010-11-11 11:11
Boardnumber : 275401089
HW-Options
=======================================
Builtin RS485
Builtin analog out
Builtin digital i/o
Operating parameter
=======================================
Access code : 0
Set Tare Key : disabled
Set zero key : disabled
Limits
=======================================
Limit 1 on : 110000
Action :set marker 1 X64=1
Condition :no condition -----
Limit 1 off : 115000
Action :clr marker 1 X64=0
Condition :no condition -----
Limit 2 on : 0
Action :set marker 2 X65=1
Condition :no condition -----
Limit 2 off : 0
Action :clr marker 2 X65=0
Condition :no condition -----
Limit 3 on : 0
Action :set marker 3 X66=1
Condition :no condition -----
Limit 3 off : 0
Action :clr marker 3 X66=0
Condition :no condition -----
Digital I/O
=======================================
Output 1 :center zero X36=1
Output 2 :standstill X38=0
Output 3 :limit 1 out X16=0
Input 1 on :set zero X112=1
Condition :no condition -----
Input 1 off : -no action-
Input 2 on :set tare X113=1
Condition :no condition -----
Input 2 off : -no action-
Input 3 on :reset tare X114=1
Condition :no condition -----
Input 3 off : -no action-
Analog out
=======================================
Analog mode :Gross D08
Analog range : 4..20mA
Output on error : 0mA
Output if < 0 : 0mA
Output if > Max : 0mA
Weight at 0/4mA : 0
Weight at 20mA : 12000
Serial assignment
=======================================
Remote display : - none -
SMA : - none -
xBPI-Port : Builtin RS485
Serial port Builtin RS485
=======================================
Protocol : no protocol
Baudrate : 9600 bd
Bits : 8
Parity : odd
Stopbits : 1
Network settings
=======================================
HW-address : 00:90:6C:6A:49:81
Hostname : PR5220-6B6A5E
Use DHCP : Yes
VNC-Client : 255.255.255.255
